4.

Electric  air conditioner (split system)

EN

Indoor unit
Outdoor unit

Capacity (cooling)  BTU (kW)

Capacity (heating) BTU (kW)

Rated power consumption (cooling) (W)

Rated power consumption (heating) (W)

Power supply V/Hz

Rated power current (cooling/heating) A

Air circulation (indoor unit) m3/h

Air circulation (outdoor unit) m3/h

Noise level (indoor unit) dB(A)

Noise level (outdoor unit) dB(A)

Refrigerant

Energy eiciency (cooling/heating)

Electrical protection class
Degree of protection against moisture

(indoor unit)
Degree of protection against moisture

(outdoor unit)
Refrigerant piping, Liquid side / Gas side, (inch)

Max. refrigerant pipe length, m

Maximum diference in level, m

Filling of Freon, g

Operating temperature range: cooling, ° C

Operating temperature range:  heating, ° C

Net weight, indoor unit (kg)

Net weight, outdoor unit (kg)

Gross weight, indoor unit (kg)

Gross weight, outdoor unit (kg)

Net dimensions, indoor unit (mm)

Net dimensions, outdoor unit (mm)

Packing dimensions, indoor unit (mm)

Packing dimensions, outdoor unit (mm)

3.SPECIFICATIONS

Tab.1

9207 (4945~10912) /

2,7 (1,45~3,2)

9548 (4774~11253) /

2,8 (1,4~3,3)
820(380~1350)

776(380~1540)

~

420

2500

27/30/33

52

R410A

A/A

I class

IPX4

IPX4

1/4 / 3/8

15

10

700

16°~24°

24°~ 32°

7,5

24,0

8,5

26,0

700×285×188

720×540×260

750x355x260

835×600×350

H-AR8-09H-UI139/I
H-AR8-09H-UI139/O

H-AR8-12H-UI140/I
H-AR8-12H-UI140/O

11253 (4774~3520)/

3,3 (1,4~3,52)

11935(3751~12788)/

3,5 (1,1~3,75)

1028(450-1500)

969(400-1350)
220- 240~/50

530

2500

34/37/40

52

R410A

A/A

I class

IPX4

IPX4

1/4 / 3/8

15

10

830

16°~24°

24°~ 32°

8,0

26,0

9,0

28,0

700×285×188

720×540×260

750×355×260

835×600×350

220-240~/50

3.57(1.5~5.9)/

3.37(1.7~6.7)

4.5(2.0-7.5)/

4.22(1.6-7.0)
