exposed while charging, recovering or purging the system;

That there is continuity of earth bonding.

7.Repairs to sealed components

1)During repairs to sealed components, all electrical

supplies shall be disconnected from the equipment being

worked upon prior to any removal of sealed covers, etc. If it

isabsolutely necessary to have an electrical supply to

equipment during servicing, then a permanently operating

form of leak detection shall be located at the most critical

point to warn of a potentially hazardous situation.

2)Particular attention shall be paid to the following to ensure

that by working on electrical components, the casing is not

altered in such a way that the level of protection is affected.

This shall include damage to cables, excessive number of

connections, terminals not made to original specification,

damage to seals, incorrect fitting of glands, etc.

Ensure that apparatus is mounted securely.

Ensure that seals or sealing materials have not degraded

such that they no longer serve the purpose of preventing the

ingress of flammable atmospheres. Replacement parts shall

be in accordance with the manufacturer's specifications.

NOTE: The use of silicon sealant may inhibit the

effectiveness of some types of leak detection

equipment. Intrinsically safe components do not have to

be isolated prior to working on them.

8.Repair to intrinsically safe components

Do not apply any permanent inductive or capacitance

loads to the circuit without ensuring that this will not

exceed the permissible voltage and current permitted for

the equipment in use. Intrinsically safe components are

the only types that can be worked on while live in the

presence of a flammable atmosphere. The test apparatus

shall be at the correct rating. Replace components only

with parts specified by the manufacturer. Other parts may

result in the ignition of refrigerant in the atmosphere from

a leak.

9.Cabling

Check that cabling will not be subject to wear, corrosion,

excessive pressure, vibration, sharp edges or any other

adverse environmental effects. The check shall also take

into account the effects of aging or continual vibration

from sources such as compressors or fans.

10.Detection of flammable refrigerants

Under no circumstances shall potential sources of ignition

be used in the searching for or detection of refrigerant

leaks. A halide torch (or any other detector using a naked

flame) shall not be used.

11.Leak detection methods

he following leak detection methods are deemed

acceptable for systems containing flammable refrigerants.

Electronic leak detectors shall be used to detect flammable

refrigerants, but the sensitivity may not be adequate, or

Warnings(for using R290/R32 refrigerant only)

may need re-calibration. (Detection equipment shall be

calibrated in a refrigerant-free area.) Ensure that the

detector is not a potential source of ignition and is suitable

for the refrigerant used. Leak detection equipment shall be

set at a percentage of the LFL of the refrigerant and shall be

calibrated to the refrigerant employed and the appropriate

percentage of gas (25 % maximum) is confirmed. Leak

detection fluids are suitable for use with most refrigerants

but the use of detergents containing chlorine shall be

avoided as the chlorine may react with the refrigerant and

corrode the copper pipe-work. If a leak is suspected, all

naked flames shall be removed/ extinguished. If a leakage

of refrigerant is found which requires brazing, all of the

refrigerant shall be recovered from the system, or isolated

(by means of shut off valves) in a part of the system remote

from the leak. Oxygen free nitrogen (OFN) shall then be

purged through the system both before and during the

brazing process.

12.Removal and evacuation

When breaking into the refrigerant circuit to make repairs

or for any other purpose conventional procedures shall be

used. However, it is important that best practice is followed

since flammability is a consideration. The following

procedure shall be adhered to:

 Remove refrigerant;

 Purge the circuit with inert gas;

 Evacuate;

 Purge again with inert gas;

 Open the circuit by cutting or brazing.

The refrigerant charge shall be recovered into the correct

recovery cylinders. The system shall be flushed with OFN

to render the unit safe. This process may need to be

repeated several times. Compressed air or oxygen shall

not be used for this task.

Flushing shall be achieved by breaking the vacuum in the

system with OFN and continuing to fill until the working

pressure is achieved, then venting to atmosphere, and

finally pulling down to a vacuum. This process shall be

repeated until no refrigerant is within the system. When

the final OFN charge is used, the system shall be vented

down to atmospheric pressure to enable work to take

place. This operation is absolutely vital if brazing

operations on the pipe-work are to take place.

Ensure that the outlet for the vacuum pump is not close to

any ignition sources and there is ventilation available.

13.Charging procedures

In addition to conventional charging procedures, the

following requirements shall be followed.

Ensure that contamination of different refrigerants does

not occur when using charging equipment. Hoses or lines

shall be as short as possible to minimise the amount of

refrigerant contained in them.

Cylinders shall be kept upright.

Ensure that the refrigeration system is earthed prior to

charging the system with refrigerant.

Label the system when charging is complete (if not already).


6

Warnings(for using R290/R32 refrigerant only)

Extreme care shall be taken not to overfill the refrigeration

system. Prior to recharging the system it shall be pressure

tested with OFN. The system shall be leak tested on

completion of charging but prior to commissioning. A follow

up leak test shall be carried out prior to leaving the site.

14.Decommissioning

Before carrying out this procedure, it is essential that the

technician is completely familiar with the equipment and all

its detail. It is recommended good practice that all

refrigerants are recovered safely. Prior to the task being

carried out, an oil and refrigerant sample shall be taken in

case analysis is required prior to re-use of reclaimed

refrigerant. It is essential that electrical power is available

before the task is commenced.

a) Become familiar with the equipment and its operation.

b) Isolate system electrically.

c) Before attempting the procedure ensure that:

 Mechanical handling equipment is available, if required, for

 handling refrigerant cylinders;

 All personal protective equipment is available and being

 used correctly; The recovery process is supervised at all

 times by a competent person;

 Recovery equipment and cylinders conform to the

 appropriate standards.

d) Pump down refrigerant system, if possible.

e) If a vacuum is not possible, make a manifold so that

  refrigerant can be removed from various parts of the

 system.

f)  Make sure that cylinder is situated on the scales before

 recovery takes place.

g) Start the recovery machine and operate in accordance

 with manufacturer's instructions.

h) Do not overfill cylinders. (No more than 80 % volume

 liquid charge).

i)  Do not exceed the maximum working pressure of the

 cylinder, even temporarily.

j)  When the cylinders have been filled correctly and the

 process completed, make sure that the cylinders and the

 equipment are removed from site promptly and all

 isolation valves on the equipment are closed off.

k) Recovered refrigerant shall not be charged into another

 refrigeration  system unless it has been cleaned and

 checked.

15.Labelling

Equipment shall be labelled stating that it has been

de-commissioned and emptied of refrigerant. The label

shall be dated and signed. Ensure that there are labels

on the equipment stating the equipment contains

flammable refrigerant.

16.Recovery

When removing refrigerant from a system, either for

servicing or decommissioning, it is recommended good

practice that all refrigerants are removed safely.

When transferring refrigerant into cylinders, ensure that only

appropriate refrigerant recovery cylinders are employed.

Ensure that the correct number of cylinders for holding the

total system charge is available. All cylinders to be used are

designated for the recovered refrigerant and labelled for that

refrigerant (i.e. special cylinders for the recovery of

refrigerant). Cylinders shall be complete with pressure relief

valve and associated shut-off valves in good working order.

Empty recovery cylinders are evacuated and, if possible,

cooled before recovery occurs.

The recovery equipment shall be in good working order with

a set of instructions concerning the equipment that is at hand

and shall be suitable for the recovery of flammable

refrigerants. In addition, a set of calibrated weighing scales

shall be available and in good working order. Hoses shall

be complete with leak-free disconnect couplings and in good

condition. Before using the recovery machine, check that it

is in satisfactory working order, has been properly

maintained and that any associated electrical components

are sealed to prevent ignition in the event of a refrigerant

release. Consult manufacturer if in doubt.

The recovered refrigerant shall be returned to the refrigerant

supplier in the correct recovery cylinder, and the relevant

Waste Transfer Note arranged. Do not mix refrigerants in

recovery units and especially not in cylinders. If compressors

or compressor oils are to be removed, ensure that they

have been evacuated to an acceptable level to make

certain that flammable refrigerant does not remain within

the lubricant. The evacuation process shall be carried out

prior to returning the compressor to the suppliers. Only

electric heating to the compressor body shall be employed

to accelerate this process. When oil is drained from a

system, it shall be carried out safely.

Note About Fluorinated Gasses

-Fluorinated greenhouse gases are contained in

 hermetically sealed equipment. For specific information

 on the type, the amount and the CO

2

 equivalent in tonnes

 of the fluorinated greenhouse gas(on some models),

 please refer to the relevant label on the unit itself.

-Installation, service, maintenance and repair of this unit

 must be performed by a certified technician.

-Product uninstallation and recycling must be performed

 by a certified technician.
