4.

Electric  air conditioner. Split system

EN

3.TECHNICAL CHARACTERISTICS

Tab.1

Indoor unit
Outdoor unit
Panel for Indoor unit

H-ALT3-18H/I
H-ALT3-18H/O
H-SQ3-ST1

H-ALT3-24H/I
H-ALT3-24H/O
H-SQ3-ST2

Capacity (cooling) BTU (kW)

18000 (5,175)

24000 (7,2)

Capacity (heating) BTU (kW)

19000 (5,6)

26500 (7,9)

Rated power consumption (cooling) W

1686

2361

Rated power consumption (heating) W

1642

2192

Power supply V/Hz

220-240~/50

220-240~/50

Rated power current (cooling/heating) A

7,66/7,46

10,73/11,0

Air circulation (indoor unit) m

3

/h

1000/820/700

1250/1050/900

Air circulation (outdoor unit) m

3

/h

-

-

Noise level (indoor unit) dB(A)

41/38/34

43/41/37

Noise level (outdoor unit) dB(A)

49/55

54/58

Refrigerant

R410А

R410A

Energy efficiency (cooling/heating)

В/В

В/A

Electrical protection class

43,2

57,6

Capacity of draining, L/d

I class

I class

Degree of protection against moisture (indoor

unit)

IPX0

IPX0

Degree of protection against moisture (outdoor

unit)

IP24

IP24

Max. refrigerant pipe length, m

25

30

Refrigerant piping, Liquid side /Gas side, (inch)

1/4 / 1/2

3/8 / 5/8

Maximum difference in level, m

15

15

Filling of Freon, g

1830

2100

Operating temperature range: cooling, ° C

+21~+43

+21~+43

Operating temperature range:  heating, ° C

-15~+30

-15~+30

Net weight, indoor unit (kg)

20

27

Net weight, panel (kg)

5

5

Net weight, outdoor unit (kg)

42

54

Gross weight, indoor unit (kg)

23

31

Gross weight, panel (kg)

8

8

Gross weight, outdoor unit (kg)

47

59

Net dimensions, indoor unit (mm)

575×260×575

830x230x830

Net dimensions of panel for indoor unit (mm)

650×30×650

950x45x950

Net dimensions, outdoor unit (mm)

780×605×290

900×650×310

Packing dimensions, indoor unit (mm)

725×300×725

950×250×950

Packing dimensions of panel for indoor unit (mm)

760×100×760

1035x90x1035

Packing dimensions, outdoor unit (mm)

883×412×653

1015×720×425
