9.

Electric  air conditioner. Split system

EN

control board.
In order to avoid malfunction of the remote control board do not insert used batteries or batter-
ies of various types.
If the conditioner is not used for a long time, remove batteries from the board or else electrolyte
may leak and damage the board.
In normal operation of the conditioner average service life of batteries will be about a half-year.

Replace batteries, if command receiving is not confirmed with an audio signal, or if the display

does not show a sign of command transfer. When generating commands from the remote con-
trol board, point an IR-radiator at a remote-control signal receiver situated on the indoor unit.
Hold the remote control board at the distance of no more than 8 m from the indoor unit. The re-
mote control board will not work, if there are any curtains, doors or other things between it and
the indoor unit. Protect the board from water and exposure to direct sunlight and heat sources.

7. OPERATING MODES

AUTO mode

The auto mode is turned on and off with the use of the button «MODE» on the remote control

board.
During operation in this mode, the air conditioner automatically selects the cooling/heating/fan
mode maintaining the set temperature.

COOL, HEAT and FAN

1.  Turn the conditioner on pressing the

«

ON/OFF

»

 button.

2.  Pressing the

«

MODE

»

 button, select COOL, HEAT or FAN mode manually.

3.  Pressing the

«

TEMP

»

 button (up-down), set the desired air temperature indoors (except for

FAN mode).

4.  Pressing the

«

FAN SPEED

»

 button on the remote control board, select the fan rotation speed:

AUTO, LOW, MIDDLE, HIGH, and the conditioner will start working in accordance with the
selected setting.

5.

To turn the conditioner off, press the «

ON/OFF

»

 button once again.

In the FAN mode air temperature indoors is not set.

DRY

Turn the conditioner on pressing the

«

ON/OFF

»

 button. Pressing the “MODE” button, select the

DRY mode. The conditioner will start working in the set mode. To turn the conditioner off, press

the

«

ON/OFF

»

 button once again.

When indoor temperature decreases to 10°C, the air conditioner is automatically switched off
and it resumes work after increase of temperature up to 12°C.

TIMER mode

Procedure of timing:
1. Press the Timer ON button to activate Timer ON. Each time you press the button you increase the

activation time by 30 minutes ranging from 0 to 10 hours and by 1 hour ranging from 10 to
