10.

Electric  air conditioner. Split system

11.

Electric  air conditioner. Split system

EN

EN

«MAXI» mode («TURBO»)

When pressing the «MAXI» button on the remote control board, the conditioner will start working

in turbo mode  for maximum cooling (in cool mode) or for maximum heating (in heat mode).

«TIMER» mode

Using button «TIMER OFF» to initiate the of-delay timer.

Using button «TIMER ON» to initiate the on-delay timer.

Each pressing of the button increases the timer setting by 30 min. When the reading reaches 10
hours, each pressing will increase the timer setting by 60 min. To deactivate the automatic timer
function, set the value at 0.0.

«SLEEP» mode

Using this button to activate the economy mode. Press it once again to deactivate the mode. This
function can be activated in the Cooling, Heating, and Auto modes.

When the ON/OFF, FAN SPEED, SLEEP, or MODE button is pressed, this mode is automatically

deactivated.

8. MAINTENANCE

•  Before cleaning switch the conditioner of.
•

Cleaning of the indoor unit and remote control board:

•  Indoor unit and remote control board should be cleaned with a dry sot cloth.
•

 If the indoor unit is too unclean, moisten the cloth with cold water.

•

 It is prohibited to clean the remote control board with moist cloth.

•

 In order to avoid the damage of paint or details of the conditioner, do not clean it with brushes
and do not leave them on the surface of indoor unit.

•

In order to avoid the damage of surface or deformation of the conditioner details, do not clean
it with petrol, solvents, cleaning powders or other chemically active substances.

•

Before a sustained interruption in the conditioner work:

•

 Turn the conditioner on for several hours in the FAN mode. It will allow you to dry its inner
cavities

•  Switch the conditioner of.
•

Remove the batteries from the remote control board.

•

Checks before starting:

•  Make sure that an air ilter is installed.
•

Make sure that air inlet and return air grillages of the outdoor unit are not blocked by foreign

objects.

•  Cleaning of air ilter
•  Air ilter cleans the air entering the conditioner from dust and foreign particles. If the ilter

is contaminated, the conditioner capacity decreases sharply. If the conditioner is operated

permanently, the ilter should be cleaned once per two weeks.

•  If the conditioner is installed in a room with dusty atmosphere, then the air ilter should be

cleaned more oten.

•  To remove the ilter, open the air inlet of the indoor unit panel. Press the locks to the center

and pull the grillages down. Remove the air inlet. Remove the air ilter. Clean the ilter with a
vacuum cleaner or rinse it in clean water. If the ilter is contaminated heavily, clean it with a
sot brush and wash in diluted washing solution, then dry it in a cool place.

•  While cleaning the ilter with the vacuum cleaner, hold it with contaminated surface up. While

washing the ilter in water, hold it with contaminated surface down.

•  Do not dry the ilter in the sun or near a ire.
•  Set the air ilter to initial position and close an air inlet cover.

9. TROUBLESHOOTING

Failures and their possible reasons:

10. SERVICE LIFE

Service life of the appliance is 10 years provided that the respective installation and operation

rules are observed.

Date of the conditioner manufacture is shown in a serial number of the device. For more details,
please, ask a shop assistant.

11. UTILIZATION RULES

Upon expiration of the service life, the appliance should be utilized in accordance with norms,

regulations and procedures efective in the place of utilization.

The conditioner

does not work

Insuicient cooling

or heating capacity

The conditioner

works, but does not

cool or heat the

room

Interruptions in power supply

Batteries in the remote control board

are low

Time of turning on is set by the timer

The set air temperature is too high or

too low

The air ilter is clogged with dust

Foreign objects block the air inlet and

return air grillages of the outdoor unit

or indoor unit

A three-minute delay of compressor

turning on

The air temperature is set incorrectly

Wait for restoration of power

supply

Replace the batteries

Wait till the conditioner turns

on by the timer or cancel the

timer setting

Set the air temperature

correctly

Clean the air ilter

Remove foreign objects

Wait a little

Set the temperature correctly

Failure

Possible reason

Actions
