9.
Electric air conditioner. Split system
EN
Work with remote control board
Mounting and replacement of batteries: mount two LR03 alkaline batteries, according to polarity
indicated on the remote control board.
In order to avoid malfunction of the remote control board do not insert used batteries or batter-
ies of various types.
If the conditioner is not used for a long time, remove batteries from the board or else electrolyte
may leak and damage the board.
In normal operation of the conditioner average service life of batteries will be about a half-year.
Replace batteries, if command receiving is not conirmed with an audio signal, or if the display
does not show a sign of command transfer. When generating commands from the remote con-
trol board, point an IR-radiator at a remote-control signal receiver situated on the indoor unit.
Hold the remote control board at the distance of no more than 8 m from the indoor unit. The re-
mote control board will not work, if there are any curtains, doors or other things between it and
the indoor unit. Protect the board from water and exposure to direct sunlight and heat sources.
7. OPERATING MODES
«AUTO» mode
The auto mode is turned on and of with the use of the button «MODE
» on the remote control
board.
1. During operation in the AUTO mode, the set temperature is maintained. In this mode, the air
conditioner automatically selects the COOLING, VENTILATION, or HEATING mode based on the
set and current temperatures.
2. In the automatic mode, the fan rotation speed is selected automatically and cannot be set
manually.
3. If the AUTO mode does not provide comfort conditions, select the mode manually. In auto-
matic mode, depending on air temperature in the room, the conditioner will select needed
temperature parameters of its operation in the following order:
«COOL», «HEAT» and «FAN»
1. Turn the conditioner on pressing the «ON/OFF» button.
2. Pressing the «MODE» button, select COOL, HEAT or FAN mode manually.
3. Pressing the «TEMP» button (up-down), set the desired air temperature indoors (except for
FAN mode).
4. Pressing the «FAN SPEED» button on the remote control board, select the fan rotation speed:
AUTO, LOW, MIDDLE, HIGH, and the conditioner will start working in accordance with the
selected setting.
5.
To turn the conditioner of, press the «ON/OFF
» button once again.
In the «FAN» mode air temperature indoors is not set.
«DRY»
Turn the conditioner on pressing the «ON/OFF» button. Pressing the «MODE» button, select the
DRY mode. The conditioner will start working in the set mode. To turn the conditioner of, press
the «ON/OFF» button once again.
12. Button «SPEED». Using this button, you
may select rotation speed of the indoor
unit fan: «Auto», «High», «Middle», «Low».
13. Button «TEMP» (increase) for setting of
the required air temperature from 17 to
30°С. Using this button, you may set the
required air temperature indoors.
