Fig. 3

Fig. 1

Fig. 2

Fig. 4

Fig. 6

This figure shows the control display when all indicator lamps are on. It may differ from the actual display.

Fig. 5

CONTENTS

SAFETY PRECAUTIONS .................................. En-1

FEATURES AND FUNCTIONS ......................... En-2

NAME OF PARTS .............................................. En-3

PREPARATION .................................................. En-4

OPERATION ...................................................... En-6

ADJUSTING THE DIRECTION OF

AIR CIRCULATION ............................................ En-8

SWING OPERATION ......................................... En-9

TIMER OPERATION ........................................ En-10

SLEEP TIMER OPERATION ............................ En-11

ECONOMY OPERATION ................................. En-12

SAFETY PRECAUTIONS

●

Do not attempt to install this air conditioner by yourself.

●

This unit contains no user-serviceable parts. Always consult authorized service per-
sonnel for repairs.

●

When moving, consult authorized service personnel for disconnection and installa-
tion of the unit.

●

Do not become excessively chilled by staying for lengthy periods in the direct cooling
airflow.

●

Do not insert fingers or objects into the outlet port or intake grilles.

●

Do not start and stop air conditioner operation by disconnecting the power supply
cord and so on.

●

Take care not to damage the power supply cord.

●

In the event of a malfunction (burning smell, etc.), immediately stop operation, dis-
connect the power supply plug, and consult authorized service personnel.

●

If the power supply cord of this appliance is damaged, it should only be replaced by
the authorized service personal, since special purpose tools and specified cord are
required.

●

Provide occasional ventilation during use.

●

Do not direct air flow at fireplaces or heating apparatus.

●

Do not climb on, or place objects on, the air conditioner.

●

Do not hang objects from the indoor unit.

●

Do not set flower vases or water containers on top of  air conditioners.

●

Do not expose the air conditioner directly to water.

●

Do not operate the air conditioner with wet hands.

●

Do not pull power supply cord.

●

Turn off power source when not using the unit for extended periods.

●

Check the condition of the installation stand for damage.

●

Do not place animals or plants in the direct path of the air flow.

●

Do not drink the water drained from the air conditioner.

●

Do not use in applications involving the storage of foods, plants or animals, precision
equipment, or art works.

●

Connection valves become hot during Heating; handle with care.

●

Do not apply any heavy pressure to radiator fins.

●

Operate only with air filters installed.

●

Do not block or cover the intake grille and outlet port.

●

Ensure that any electronic equipment is at least one metre away from either the in-
door or outdoor units.

●

Avoid installing the air conditioner near a fireplace or other heating apparatus.

●

When installing the indoor and outdoor unit, take precautions to prevent access to
infants.

●

Do not use inflammable gases near the air conditioner.

DANGER!

CAUTION!

En-1

HI-POWER OPERATION ................................. En-12

COIL DRY OPERATION ................................... En-13

AUTOMATIC FILTER CLEANING

FUNCTION ...................................................... En-14

PERFOMING MAINTENANCE ........................ En-16

PERFOMING MAINTENANCE

(CONTINUED) ................................................. En-19

MANUAL AUTO OPERATION ........................ En-21

TROUBLESHOOTING ..................................... En-22

OPERATING TIPS ............................................ En-23
