General Fujitsu ASHA09LEC - Инструкция по эксплуатации - Страница 3

CONTENTS

SAFETY PRECAUTIONS .................................... En-1

FEATURES AND FUNCTIONS ........................... En-2

NAME OF PARTS ................................................ En-3

PREPARATION .................................................... En-4

OPERATION ........................................................ En-5

TIMER OPERATION ............................................ En-7

SLEEP TIMER OPERATION ................................ En-8

ADJUSTING THE DIRECTION OF

AIR CIRCULATION .............................................  En-9

10°C HEAT OPERATION ................................... En-10

ECONOMY OPERATION ................................... En-10

SWING OPERATION ......................................... En-11

COIL DRY OPERATION ..................................... En-11

MANUAL AUTO OPERATION .......................... En-11

CLEANING AND CARE ..................................... En-12

TROUBLESHOOTING ....................................... En-14

OPERATING TIPS .............................................. En-15

SAFETY PRECAUTIONS

●

Do not attempt to install this air conditioner by yourself.

●

This air conditioner contains no user-serviceable parts. Always consult authorized serv-
ice personnel for repairs.

●

When moving, consult authorized service personnel for disconnection and installa-
tion of the air conditioner.

●

Do not become excessively chilled by staying for many hours in the direct cooling
airflow.

●

Do not insert fingers or objects into the outlet port or intake grille.

●

Do not start and stop air conditioner operation by disconnecting the power supply
cord and so on.

●

Take care not to damage the power supply cord.

●

In the event of a malfunction (burning smell, etc.), immediately stop operation, dis-
connect the power supply plug, and consult authorized service personnel.

●

If the power supply cord of this appliance is damaged, it should only be replaced by
the authorized service personal, since special purpose tools and specified cord are
required.

●

Provide occasional ventilation during use.

●

Do not direct airflow at fireplaces or heating apparatus.

●

Do not climb on, or place objects on, the air conditioner.

●

Do not hang objects from the indoor unit.

●

Do not set flower vases or water containers on top of  air conditioners.

●

Do not expose the air conditioner directly to water.

●

Do not operate the air conditioner with wet hands.

●

Do not pull power supply cord.

●

Turn off power supply when not using the indoor unit for extended periods.

●

Check the condition of the installation stand for damage.

●

Do not place animals or plants in the direct path of the airflow.

●

Do not drink the water drained from the air conditioner.

●

Do not use in applications involving the storage of foods, plants or animals, precision
equipment, or art works.

●

Connection valves become hot during Heating; handle with care.

●

Do not apply any heavy pressure to radiator fins.

●

Operate only with air filters installed.

●

Do not block or cover the intake grille and outlet port.

●

Ensure that any electronic equipment is at least one meter away from either the in-
door or outdoor units.

●

Avoid installing the air conditioner near a fireplace or other heating apparatus.

●

When installing the indoor and outdoor unit, take precautions to prevent access to
infants.

●

Do not use inflammable gases near the air conditioner.

DANGER!

CAUTION!

En-1
