SVEN RX-G810 - Инструкция по эксплуатации - Страница 19

ENG

19

RX-G810

User’s Manual

Creating macros

1. The “Макрос” tab lets you create the exact sequence of keystrokes and buttons. This tab

also  allows  you  to  customize  macros  and  long  macros  for  the  tasks  you  need.  Assigning

a macro to a key makes it easy to perform complex operations. To create a macro, you must

do the following:

Press button

, enter any macro name in the window and click «OK». The name of the en

-

tered macro will appear in the “Macro list”

2. Press button

— macros will start recording. Type on the keyboard the macro that will

execute when you click the highlighted mouse button. The entered macros will be displayed

in the window.

3. Press button

— the program will save the entered characters.

4. Then you must press the key combination you want to use later. The keys you press will be

displayed in the “Key list” window.

5. To stop recording, press the “Stop” button. The program will save the macro settings.

Press  button

,  you  can  edit  the  delays  between  macros.  The  sign  button

deletes

the macro. By selecting the «Cycles» checkbox, you can select the number of repetitions.

TROUBLESHOOTING

Problem

Solution

The mouse

is not working.

1. Disconnect the mouse from the PC and check connector

pins for possible damage. If there is no external damage found

and connector pins are OK, connect the mouse to the PC.

2. Address your nearest authorized service center.

TECHNICAL SPECIFICATIONS

Parameter, measurement unit

Value

OS compatibility

Windows

Type of mouse

optical

Resolution, dpi

800–4000

Q-ty of buttons

5 + 1 (scroll wheel)

Interface

USB

Сable length, m

1.8

Dimensions, mm

126 × 68 × 40

Weight, g

145

Notes.  Technical  specifications  given  in  this  table  are  supplemental  information

and  cannot  give  occasion  to  claims.  Technical  specifications  are  subject  to  change

without notice due to the improvement of SVEN production.
