Cables and Speeds

The following table describes the network cables that you can use for the
switch connections and the speeds that these cables can support, up to
100 meters (328 feet).

Speed

Cable Type

100 Mbps

Category 5 (Cat 5) of higher rated

1 Gbps, 2.5 Gbps, or 5 Gbps

Category 5e (Cat 5e) or higher rated

10 Gbps

Category 6A (Cat 6A) or higher rated.

Note:

For speeds of 10 Gbps, if the cable length is shorter than 55 meters

(180 feet), you can use a Category 6 (Cat 6) cable.

SFP Transceiver Modules

SFP+ fiber ports accommodate standard small form-factor pluggable (SFP)
gigabit interface converters (GBICs, also referred to as transceiver modules)
for fiber connectivity. GBICs are sold separately from the switch.
The following table describes the NETGEAR SFP transceiver modules and
direct attach cables (DACs) that the switch supports.

Speed and Medium

Model

Description

1G Ethernet short-reach fiber

AGM731F SFP transceiver 1000BASE-SX

1G Ethernet long-reach fiber

AGM732F SFP transceiver 1000BASE-LX

1G Ethernet copper

AGM734

SFP transceiver 1000BASE-T

10G Ethernet short-reach fiber

AXM761

SFP+ transceiver 10GBASE-SR

10G Ethernet long-reach fiber

AXM762

SFP+ transceiver 10GBASE-LR

10G Ethernet long-range multimode fiber AXM763

SFP+ transceiver 10GBASE-LRM

Support

Thank you for selecting NETGEAR products. You can visit

www.netgear.com/support

 to register your product, get help, access the latest

downloads and user manuals, and join our community. We recommend that you
use only official NETGEAR support resources.

For the current EU Declaration of Conformity, visit

http://support.netgear.com/app/answers/detail/a_id/11621/

.

For regulatory compliance information, visit

http://www.netgear.com/about/regulatory/

.

See the regulatory compliance document before connecting the power supply.

Si ce produit est vendu au Canada, vous pouvez accéder à ce document en
français canadien à

http://downloadcenter.netgear.com/other/

.

(If this product is sold in Canada, you can access this document in
Canadian French at

http://downloadcenter.netgear.com/other/

.)

Speed and Medium

Model

Description

10G Ethernet

AXC761

SFP+ DAC, 1 meter

10G Ethernet

AXC763

SFP+ DAC, 3 meters

Specifications

Specification

Description

Network interfaces

Model XS505M:
•Four 10G/Multi-Gigabit Ethernet RJ-45 ports that support
100M, 1G, 2.5G, 5G, and 10G
•One SFP+ port that supports 1G and 10G

Model XS508M:
•Seven 10G/Multi-Gigabit Ethernet RJ-45 ports that support
100M, 1G, 2.5G, 5G, and 10G
• One combo port that allows you to use either one of the
following ports (you cannot use both ports simultaneously):

- Port 8, which is an Ethernet RJ-45 port that supports 1G
and 10G
- Port 8F, which is an SFP+ port that supports 1G and 10G

Power consumption

Model XS505M: 25W

Model XS508M: 40W

Dimensions (W x D x H) 12.91 x 6.65 x 1.7 in. (328 x 169 x 43.2 mm)

Weight

Model XS505M: 3.0 lb (1.38 kg)

Model XS508M: 3.3 lb (1.49 kg)

Operating temperature

32–122°F (0–50°C)

Operating humidity

10%–90% relative humidity, noncondensing.
