Supplied parts

1  Coffee / tea maker

1  Filter holder

1  Permanent filter

1  Cup shelf

1  Drip tray

1  Stainless steel thermo cup

1  Glass cup

Initial Operation of the Device

1.  Remove all packaging and transportation safety devices

from the device that may be present.

2.  Rub all of the parts with a damp cloth. This will remove any

dust that may have accumulated during transport.

3.  Clean the filter holder, the permanent filter and the cups in

a bowl of water.

4.  Reinsert all of the parts in the reverse order.

NOTE:

Before brewing beverages for the first time, run water through

the appliance four times to clean it.

•  Pour 300 ml fresh water into the water tank.

•  Place the cups on the cup shelf.

•  Turn the selector to

“COFFEE”

.

•  When the cup is full, turn the selector to

“OFF”

 and pour

the water away.

•  After filling the water tank twice, turn the selector from

“COFFEE”

 to

“HOT WATER”

.

Electrical Connection

NOTE:

Please ensure that the device is switched off. The switch

must be on

“OFF”

.

Insert the mains plug into a properly installed socket with earth-

ing contact. For information please see the type plate on the

device.

The red indicator lamp indicates that the power supply is on.

Operation

Preparing coffee or hot water

NOTE:

•  The coffee filter is located on the left hand side.

•  The hot water spout is on the right hand side.

•  You can pour up to 300 ml of water into the water tank to

brew 2 – 3 consecutive cups of coffee or tea.

1.  Open the water tank cover.

2.  Pour cold water into the water tank.

NOTE:

•  To fill the water tank with the correct amount of water,

use the cup which you then want to use for brewing

the beverage.

NOTE:

•  The coffee powder will absorb water. The amount

of coffee is thus somewhat less than the original

amount of water.

CAUTION:

Do not overfill the water tank! Do not fill beyond the MAX

(300 ml) mark.

3.  Close the water tank cover.

4.  To prepare coffee, pull out the filter holder. Pour the coffee

into the permanent filter (approx. 6 g for one cup, max.

12 g according to personal taste). Slide the filter holder

back under the filter. The holder must audibly click into

place. Place a cup onto the cup shelf under the coffee filter.

5.  To prepare an infusion with hot water, place a cup under

the right hand spout.

6.  Select the type of preparation:

a)  For coffee, turn the selector to

 “COFFEE”

.

b)  For hot water, turn the selector to

“HOT WATER”

.

  The brewing process begins. The green indicator lamp

lights up.

NOTE:

The brewing process for one cup of 125 ml lasts around

3½ minutes. It ends when the water in the tank has been

used up.

7.  If you want to cancel or end the brewing process, turn the

selector to

“OFF”

. The green indicator lamp goes out.

8.  After the brewing process, you can remove the cup. Watch

out for dripping.

WARNING:

Cold water on the hot heating element may splash and

injure you!

Allow the appliance to cool for 3 minutes, before refilling

the water tank.

End of use

1.  Turn the selector to

“OFF”

. The green indicator lamp goes

out.

2.  Disconnect from the mains. The red indicator lamp goes

out.

Descaling

It is necessary to descale the coffee machine if the preparation

time becomes considerably longer.
•  Only a commercially available decalcifier on a citric acid

base should be used for descaling.

•  Please use the quantities stated on the pack or instruction

leaflet. Do not exceed to maximum volume of water!

•  Place the cups or another suitable vessel (for around

300 ml) onto the cup shelf.
