Color Variants
CM470112

Stainless steel behind glass-backed full

glass door

Width 60 cm

Included accessories

1 x assembly screws.

1 x scoop.

1 x test strip.

1 x milk container (insulated).

1 x connection hose for milk frother.

1 x milk pipe.

CM470112
Fully automatic espresso machine 400

series
Stainless steel behind glass-backed full

glass door
Width 60 cm
Controls at the top

Handleless door / automatic door

opening

Fixed inlet and outlet water connection

Continuous flow heater means no

waiting time and constant brewing

temperature

Aroma brewing technology for a full

aroma

Single portion cleaning

TFT touch display

Panel-free appliance with surface

control module

One-touch operation

Personalisation function

7 light settings

Electronic fill level control for milk,

water and coffee to ensure a perfect

result

Type of beverage

Ristretto / 2 x Ristretto.
Espresso / 2 x Espresso.
Espresso Macchiato / 2 x Espresso

Macchiato.
Coffee / 2 x Coffee.
Americano / 2 x Americano.
Caffe Latte / 2 x Caffe Latte.
Latte Macchiato / 2 x Latte Macchiato.
Cappuccino / 2 x Cappuccino.
Flat White / 2 x Flat White.
Milk froth / 2 x Milk froth.
Warm milk / 2 x Warm milk.
Hot water / 2 x Hot water.

Handling

Automatic door opening.

Rotary knob and TFT touch display

operation.

Clear text display.

Personalisation function, option to save

8 individualised beverages.

4 beverage size settings, volume can be

individually adjusted to match the size

of the cup.

8 coffee strength levels from very mild

to extra strong.

3 coffee temperature levels.

10 hot water temperature levels.

4 coffee-milk ratio levels.

Adjustable grinding level.

Height-adjustable coffee dispenser 7

cm to 15 cm.

Easy access to water tank, milk and

coffee bean container behind the door.

Features

Maintenance-free grinding unit with

ceramic discs.

Separate drawer for second ground

coffee type.

Water pump with 19 bar pressure.

Double grinding and brewing cycles

for extra intensity for single beverage

order.

For double beverage order, two

grinding and brewing cycles.

Beverage dispenser with integrated

milk system.

Insulated stainless steel milk container

for up to 0.5 litres.

Integrated lightning with LEDs.

Removable bean container with aroma

protecting lid for 500 g allows for an

effortless exchange of different types

of coffee beans.

Automatic adjustment of ground coffee

quantity.

Removable 2.4 litre water tank.

Electronic water filter exchange

indicator.

Characteristics
Built-in / Free-standing

Built-in

Frothing nozzle

No

Display

No

Water protection system

yes

Portion sizes

All cups

Dimensions

455 x 590 x 537

Dimensions of the packed product

(HxWxD) (mm)

540 x 620 x 670

Required niche size for installation

(HxWxD)

449 x 558 x 347

Hot water spout

No

Adjustable programs
Standby function

Yes

Pump pressure (bar)

19

Simultaneous preparation of 2 cups

Yes

Included accessories

1 x assembly screws, 1 x scoop, 1 x test

strip, 1 x milk container (insulated), 1

x connection hose for milk frother, 1 x

milk pipe

Optional accessories
Electrical connection rating (W)

1600

Current (A)

10

Voltage (V)

220-240

Frequency (Hz)

50/60

Plug type

Gardy plug w/ earthing

Product group

Built-in coffee machine

Brand

Gaggenau

Product name/family
Product name / Commercial code

CM470112

Universal Product Code
Main colour of product

Stainless steel behind glass

Typology

Fully automatic
Australia Standards, CE, Eurasian,

Ukraine, VDE

Length electrical supply cord (cm)

170.0

Length of electrical supply cord (in)
Reccommended height for installation

(in)
Reccommended height for installation

(mm)

449

Appliance Dimensions (h x w x d) (in)
Dimensions

455 x 590 x 537

Dimensions of the packed product (in)
Dimensions of the pallet (in)
Dimensions of the packed product

(HxWxD) (mm)

540 x 620 x 670
59

Net weight (kg)

26.760
65

Gross weight (kg)

29.4

Capacity water container

2.4

Consumption and connection features
2021-02-26

Page 1

Fresh water-function to refill the water

tank with fresh water.
Electronic fill level control for drip tray

and container for coffee residue.
Home network integration for digital

services (Home Connect) either via

cable connection LAN (recommended)

or wireless via WiFi.
The use of the Home Connect

functionality depends on the Home

Connect services, which are not

available in every country. For further

information please check: home-

connect.com.

Safety

Child lock.
Aqua stop with guarantee.

Cleaning

Fully automatic rinse programme when

machine is turned on/off.
Automatic steam cleaning of the milk

system after every beverage.
Automatic cleaning and descaling

programme.
Emptying programme to prepare the

appliance for holiday or transportation.
Empty-grinding function to remove

coffee residues from the system when

switching bean types.
Removable brewing unit.
Dishwasher-safe coffee residue

container and drip tray.
Dishwasher-safe beverage dispenser.

Planning notes

Ideal installation height 95 cm to 145

cm (top edge of niche bottom).
The door panel surface of the

appliance extends 47 mm from the

furniture cavity.
When installing in a corner a side

clearance is required.
Door opening angle appr. 110°

(delivery status) - mounting distance to

the wall has to be at least 350 mm.
Door opening angle appr. 155° -

mounting distance to the wall has to be

at least 650 mm.
Door opening angle appr. 92° -

mounting distance to the wall has to

be at least 100 mm (spare part No.

00636455).
Installation directly above 14 cm high

warming drawer in 59 cm standardised

niche.
At no point may the outlet hose be

positioned higher than the bottom edge

of the appliance. The outlet hose must

also be at least 150 mm lower than the

appliance outlet (see drawing "drainage

connection").
If the appliance is placed too far from

the main siphon, the drain system

has to be adjusted on-site (building

installation).
The water connection (1) for the inlet

hose must always be accessible

and not located directly behind the

appliance.
The connection of the outlet hose to

the siphon (2) must not be directly

behind the appliance and should be

accessible.
The LAN port can be found at the back

on the lower right side.
Special accessories (order as spare

parts):
Part No. 17000705 Water filter
Part No. 00311819 Descaling tablets
Part No. 00311769 Cleaning tablets
Part No. 00636455 Door hinge restrictor

(92° opening angle)
Part No. 11015223 Bean container with

lid

Connection

Total connected load 1.6 KW.
Connection cable 1.7 m with plug.
Only cold water connection.
Inlet hose 165 cm with 3/4 " (26.4 mm)

connection, extendable.
Outlet hose (ø 18 mm) 170 cm (HT-

Hose).
Plan a LAN cable.
Power consumption standby/display on

1.0 W.
Power consumption standby/display off

0.5 W.
Power consumption standby/network

2.0 W.
Time auto-standby/display on 30 min.
Time auto-standby/display off 30 min.
Time auto-standby/network 30 min.
Please check the user manual for how

to switch off the WiFi module.
