4

en

1

  Power on/off switch

O / I

 2

  Customising button

á

3

  Service programmes button

à

4

  Selection buttons

<

>

 5

 Display

a)

 Status line

b)

 Selection line

c)

 Navigation line

6

  Rotary knob for display settings

7

  Info menu button

j

8

start

button  (drinks / programmes)

9

   Coffee  outlet,

height-adjustable and swivelling

10

   Milk  system,

height-adjustable and removable
(milk / hot  water)

a)

 Upper part

b)

 Lower part

c)

 Suction hose

d)

 Suction pipe

11

  Removable water tank

12

  Lid for water tank

13

   Storage compartment for

measuring spoon

14

   Measuring  spoon

(insertion aid for water ilter)

15

  Bean container

16

  Aroma cover

17

  Selector for grind setting

 18

   Powder  compartment

(ground  coffee / cleaning  tablet)

 19

  Door to brewing unit

20

  Brewing unit

a)

 Lock

b)

Cover

21

  Sliding button

22

   Storage compartment for

quick  reference guide

 23

  Drip tray

a)

 Panel

b)

 Grate

c)

Coffee grounds container

 24

  Cable storage compartment

25

  Rating label (E-No.; FD)

 26

  Milk container, insulated

27

  Cup warming function

 28

   Button for cup warming function,

illuminated

 29

  Water ilter

Included in delivery

(Figure

 A

 on the fold-out pages)

1

    Fully automatic espresso machine

TE809

2

   Instruction  manual

3

   Quick reference guide

4

   Milk  frother

5

   Water hardness testing strip

6

   Measuring  spoon

7

   Milk container, insulated

8

   Water ilter

At a glance

(Figures

 B, C, D, E

and

 F

 on the fold-out pages)
