REMEZair RMCH-403-01 - Инструкция по эксплуатации - Страница 10

ENG

The wide angle airflow ensures quick and even distribution of heat throughout the room.

4. Air heating

Two modes of air heating

By pressing the «Heat» button again, the heater

operates at an maximum speed of 1500 W.

In Heating mode, you cannot use the Cooling or
Humidifying function.

The modular filter system in the device allows you to easily and quickly replace filter

modules and choose the mode of air purification you need.

5. Air purification

Module No.1 «Humidification/
Cooling and Aqua Filtration». In this
mode, the device provides natural

cooling and humidification of the air,
and the aqua filtration process traps
dust and household allergens.

Module No.2 «Composite HEPA +
Carbon Filter». The three-stage
filtration system in this mode allows

deep purification of the air from the
smallest particles of dust and other

household allergens, and the carbon
filter eliminates unpleasant odors.

Attention

When using the «Composite HEPA + Carbon Filter» module in the device, you cannot use
the «Humidification and Cooling» mode. Water contact on the HEPA filter and the carbon
filter has an extremely negative effect on their effectiveness.

Click the button «Purify»       to enable the ionization function. The corresponding indicator
will light up on the display.

IonWind technology saturates the air with air ions, making it fresh and clean and
significantly improves human well-being. The climatic complex generates 4800-5100 air
ions per cm

3

, which corresponds to forest and sea air. This concentration of air ions is not

contraindicated for people suffering from bronchial asthma. When the device is turned on,

the ionisation function is automatically activated.

6. Ionizer

Press the «Timer»       button, to turn on the timer. The timer is convenient to use for

automatic shutdown of the Climate Station. The time selection range is 0-15 hours in 1 hour

increments.

7. Timer

Click the «Swing»       button to change the angle of rotation of the ventilation grill slats

by 80°. This function allows you to humidify, cool and heat the room more efficiently and

evenly.

8. Rotating the slats

9. Wireless charging

Wireless charging is located on the display of your device. Place a smartphone that
supports wireless charging in the designated area and the smartphone will start charging.

10. Indication of lack of water in the tank

If there is no water in the tank of the climate complex, the sensor for lack of water light
up, an audible signal will sound, and the water pump will stop working. To continue the

humidification and cooling function, you need to add water to the tank.

The fan operates according to a specific pattern and can be set to low, medium and high
speed. This mode simulates the effect of the sea breeze, making the air flow softer and
more comfortable for users. The fan speed indicator displays the initial speed value.
The number  below shows the operation of the unit in Breeze mode at high, medium and
low speeds.

Breeze mode

The fan runs at first speed with the minimum noise level, the LED display is off.

Night mode

For maximum cooling, use the two ice boxes

provided.

1. Pour tap water into the ice packs and place

them in the freezer of  a refrigerator until they

freeze.

2. Then place the ice packs in the water tank to

keep the temperature below room temperature.

3. Two ice packs ensure continuous use of the

maximum cooling function.

ICE BOXES USE

To install modules No.1 and No.2 into the device, insert the corresponding filter in the

plastic holder into the filter compartment, as shown in the figure.

Top

Top

Module No.1 Module No.2

Pressing the «Heat»       button once
the heater operates at a average
speed of 750 W.
