Multi-surface leveling laser

502

INTRODUCTION

●

This tool is intended for aligning objects and/or marking
desired cutting lines by means of a straight laser line
projection; with the accessories supplied the tool can be
used on a variety of surfaces

●

Carefully read this instruction manual as well as the
warning label on the tool, before you use the tool

1

●

Pay special attention to the safety instructions and
warnings; failure to follow these may result in
serious (eye) injury

●

Before using the tool for the first time, paste the supplied
sticker in your national language over the English text of
warning label F

3

●

Save this instruction manual for future reference

TECHNICAL SPECIFICATIONS

Laser type

635 nm

Laser class

2

Maximum power output

1 mW

Power supply

3 x AG13 button cell battery

Operating temperature

-10°C to 40°C

Storage temperature

-20°C to 60°C

Weight

0,05 kg

Accuracy

deviation of +/- 10 mm at
5 metres' distance

SAFETY

●

Do not look into the laser beam (laser radiation)

2

●

Do not point the laser beam at persons or animals

●

Do not place the tool in a position that may cause
anyone to look into the laser beam intentionally or
unintentionally

●

Do not use any magnifying optical tools (such as
magnifying glasses, telescopes, or binoculars) to view
the laser beam

●

Do not remove or damage the warning label on the tool

●

Do not operate the tool in the presence of flammable
liquids, gases or dust

●

Do not operate the tool with children around

●

This tool should not be used by people under the age of
16 years

●

Do not use the tool for any purpose other than those
mentioned in this instruction manual

●

Only use the original accessories which are intended for
this tool

●

Always switch off the tool when not in use

TOOL ELEMENTS

3

A

On/off switch

B

Bubble level for horizontal lines

C

Bubble level for vertical lines

D

Laser light opening

E

Battery compartment cover

F

Warning label

G

Suction accessory

H

Clamp accessory

J

Pin accessory

K

Magnet accessory

L

Screw accessory

M

Pivot accessory

N

Belt clip accessory

USE

●

On/off
- before first use, remove protective insert as

illustrated

4

- switch on/off the tool by pushing switch A

! do not look into the laser beam
! do not point the laser beam at persons or animals
! always switch off the tool after use

●

Changing batteries

5

! ensure that the tool is switched off

- remove cover E
- insert 3 x AG13 button cell battery (pay attention to

correct polarisation)

- mount cover E
- always remove the batteries from the tool, if the tool

is not used for a long period

- always replace the complete set of batteries

●

Operating the tool

6

- when projecting a horizontal line, ensure that the

bubble in level B is centered

- when projecting a vertical line, ensure that the bubble

in level C is centered

- make measurements using the projected line as

reference

- when projecting a laser line at a longer distance, you

may increase its visibility by placing an object at the
end of the desired distance

7

●

Suction accessory G

8

For projecting lines on smooth surfaces
- slide tool on accessory G
- place accessory G onto surface
- level the tool (ensure that the bubble in the relevant

level is centered)

- push 2 knobs
- use projected line as reference

●

Clamp accessory H

9

For projecting lines on board materials (thickness 15 -
30 mm)
- slide tool on accessory H
- fasten accessory H onto board by turning knob

clockwise

- use projected line as reference

●

Pin accessory J

0

For projecting lines on plasterboard, soft wood, and
other soft materials
- slide tool on accessory J
- place accessory J onto surface
- level the tool (ensure that the bubble in the relevant

level is centered)

- push 2 knobs
- use projected line as reference

! be aware of the sharp pins

●

Magnet accessory K

!

For projecting lines on any ferrous metal surface or profile
- slide tool on accessory K
- place accessory K onto surface

GB

7
