4

SNIPER 80

     PLUS

10. Line 2

11. Line 3

12. Tilt angle on axes X and Y

13. Battery power

14. Timer

15. Memory number

16. Memory function

17. Service

Inserting / Replacing Batteries

Remove the battery cover, insert the battery correctly. Pay

attention to correct polarity. Close the battery compart-

ment.

Replace the battery when symbol constantly blinks in the

display. Batteries should be removed in case of danger of

corrosion, if the device will not be used for a long time.

The tool is equipped with charging port for battey charging.

There is a charging port covered with rubber cap on the

side of the tool. To charge, connect the cable to the mi-

croUSB charging port, and then connect the charger to a

household electrical outlet.

Attention! Never connect the charger when using

non-rechargeable batteries. Do not leave the device un-

attended, when connecting the charger. The parameters

of the charger must comply with the parameters of the

household power supply and have an output voltage of

not more than 5 V.

MENU FUNCTIONS

Swtich on and off

Press the button ON (1) to switch on the instrument and la-

ser.

Press and hold key for about 2 seconds to start continuous

measuring.

The device also switches off automatically after 3 minutes of

inactivity i.e. no key is pressed within that interval.

To switch off the instrument press and hold button OFF (4)

for 2 sec.

Reference Setting

Default reference setting is from the rear of the device.
