Place an instrument on a firm and stable surface or a tripod.

Move compensator lock   to choose necessary operating mode:

1 Automatic leveling, to build horizontal and vertical planes and

lines:

Move compensator lock to unlocked position    . Compensator is
unlocked. If the product is out of the range of automatic compensation
it will emit sound signal.
Short press button

LINE

 to turn on necessary laser planes.

Short press button

MODE

 to switch on/off pulse mode that allows

working with laser receiver.  In this mode pulse mode indicator will
turn green.
To switch off the product move the compensator lock to locked
position        .

2 Locked compensator, to build inclined planes and lines:

Move the compensator lock to locked position      . Compensator is
locked. Short press button

MODE

 to turn on the product. Horizontal

plane will switch on. Locked pendulum indicator turns red.
Short press button

MODE

 to turn on necessary laser planes.

TECHNICAL SPECIFICATIONS

Working range/with receiver

30 m / 60 m*

Self-levelling accuracy

±0,3 mm/m

Self-levelling range

± 4,5°

Continuous working time

5 hours

Operating temperature

0°C ... +50°C

Storage temperature

-20°C ... +70°C

Tripod mounting thread

5/8’’ and 1/4’’

Dust and water protection rate

IP54

Laser type

Class II 635 nm  < 1 mW

Power supply

3 х 1.5V LR6 alkaline (AA)

Dimensions

130х73х125mm

Weight

0,45 kg

* The operating range may differ from the declared depending on the

lighting conditions.

OPERATION

Before start operation remove the battery cover, insert the batteries,

observing correct polarity. Put battery cover back.

Use alkaline AA batteries only, all batteries should be of the same type

and brand with the same charge level. Replace batteries if battery

charge level indicator turns red while operation.
