18

 | English

u

Do not direct the laser beam at persons or animals and do not stare into the laser
beam yourself (even from a distance).

To

switch off

 the measuring tool, slide the on/off switch

(2)

 to the

Off

 position. The pen-

dulum unit is locked when the tool is switched off.

u

Never leave the measuring tool unattended when switched on, and ensure the
measuring tool is switched off after use.

 Others may be blinded by the laser beam.

Operating Modes

The measuring tool has three operating modes, which can be selected at any time:

Operating mode

Cross-line mode with automatic levelling

 (see figure

A

): The measuring tool

generates one horizontal and one vertical laser line.

Cross-line and plumb point operation with automatic levelling

 (see fig-

ure

B

): The measuring tool generates a horizontal and two vertical laser lines

and a downwards plumb point. The device projects the two vertical laser lines
at a right angle to one another.

Cross-line mode with incline function

 (see figure

C

): The measuring tool gen-

erates one horizontal and one vertical laser line.

Once the measuring tool has been switched on, it is in cross-line operation with auto-
matic levelling.
To change the operating mode, press the  button for laser operating mode

(3)

 until the

required laser operating mode is displayed by the corresponding "Laser operating mode"
indicator

(5)

 lighting up.

Automatic Levelling

Working with automatic levelling

Position the measuring tool on a level, firm support or attach it to a tripod

(11)

.

Select one of the operating modes with automatic levelling.
The automatic levelling function automatically compensates irregularities within the self-
levelling range of ±

4

°. The levelling is finished as soon as the laser lines stop moving.

If automatic levelling is not possible, e.g. because the surface on which the measuring
tool stands deviates by more than

4

° from the horizontal plane, the laser switches off.

If this is the case, set up the measuring tool in a level position and wait for the self-level-
ling to take place.
In case of ground vibrations or position changes during operation, the measuring tool is
automatically levelled again. Upon levelling, check the position of the laser beams with
