14

 | English

1 609 92A 0L2 | (3.6.14)

Bosch Power Tools

Intended Use

Surface laser

The measuring tool is intended for checking the flatness of
floor surfaces.

The measuring tool is suitable for indoor use.

Remote Control (GSL 2 Set)

The remote control is intended for controlling surface lasers
indoors.

Product Features

The numbering of the product features refers to the illustra-
tion of the surface laser and remote control on the graphics
page.

Surface laser

1

Exit opening for laser beam

2

Laser warning label

3

Handle

4

Reception lens for remote control  (GSL 2 Set)

5

Battery status indicator

6

Latch of battery lid

7

Battery lid

8

On/Off switch

9

Thumbwheel for height adjustment

10

Laser target plate

11

Measuring tip of the laser target plate

12

Serial number of the surface laser

23

Battery pack *

Remote Control

13

Outlet opening for infra-red beam

14

Button for fast rotation in anticlockwise direction

15

Button for slow rotation in anticlockwise direction

16

Button for step-by-step rotation in anticlockwise
direction

17

Button for step-by-step rotation in clockwise direction

18

Button for slow rotation in clockwise direction

19

Button for fast rotation in clockwise direction

20

Battery lid of the remote control

21

Battery lid latch of the remote control

22

Serial number

Accessories/Spare parts

24

Laser viewing glasses *

25

Case

* The accessories illustrated or described are not included as
standard delivery.

Technical Data

Surface laser

GSL 2

GSL 2 Set

Article number

3 601 K64 000

3 601 K64 001
3 601 K64 070
3 601 K64 0R0

Remote-controlled, motor-driven rotation base

–



Working range

1)

– without laser target plate
– with  laser  target  plate

10 m
20 m

10 m
20 m

Levelling Accuracy

±0.3 mm/m

±0.3 mm/m

Self-levelling range, typically

±4 °

±4 °

Levelling duration, typically

< 5 s

< 5 s

Operating temperature

– 10 ° C ... + 50 ° C

– 10 ° C ... + 50 ° C

Storage temperature

– 20 ° C ... + 70 ° C

– 20 ° C ... + 70 ° C

Relative air humidity, max.

90 %

90 %

Laser class

3R

3R

Laser type

630 – 670 nm,  < 5 mW

630 – 670 nm,  < 5 mW

C

6

1

1

Batteries (alkali-manganese)
Battery pack (lithium-ion)

4 x 1.5 V LR06 (AA)

10.8 V

4 x 1.5 V LR06 (AA)

10.8 V

Battery life

– Batteries (alkali-manganese)
– Battery pack (lithium-ion) (1,3 Ah)
– Battery pack (lithium-ion) (1,5 Ah)

15 h
15 h
25 h

15 h
15 h
25 h

Weight according to EPTA-Procedure 01/2003

1.4 kg

1.4 kg

Dimensions (length x width x height)

210 x 195 x 205 mm

210 x 195 x 205 mm

Degree of protection

IP 54 (dust and splash water protected) IP 54 (dust and splash water protected)

1) The working range can be decreased by unfavourable environmental conditions (e. g. direct sun irradiation).

For clear identification of your surface laser, see the serial number

12

 on the type plate.
