Display Elements (see figure A)

a

Switched-off audio signal indicator

b

Warning-function indicator

c

Indication of the object type “Non-metal object”

d

Indication of the object type “Non-magnetic metal”

e

Indication of the object type “Magnetic metal”

f

Indication of the object type “Live conductor”

g

Temperature control indicator

h

Battery indicator

i

Measuring indicator

j

Fine scale

k

Indication

“CENTER”

Technical Data

Declaration of Conformity

We declare under our sole responsibility that the product

described under “Technical Data” is in conformity with the fol-

lowing standards or standardization documents:

EN 61010-1:2010-10, EN 61326-1:2006-05,

EN 301489-3:2002-08, EN 301489-1:2008-04,

EN 300330-1:2010-02, EN 300330-2:2010-02 according

to the provisions of the directives 2011/65/EU,

2004/108/EC, 1999/5/EC.

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

Leinfelden, 02.03.2012

Assembly

Inserting/Replacing the Battery

Alkali-manganese batteries are recommended for the meas-

uring tool.
To open the battery lid

14

, press the latch

15

 in the direction

of the arrow and fold up the battery lid. Insert the supplied

battery. Pay attention that the polarity is correct, according to

the representation on the inside of the battery lid.
The battery indicator

h

 always indicates the current battery

status:
–

Battery fully charged

–

Battery has 2/3 of its capacity or less

–

Battery has 1/3 of its capacity or less

–

Please change battery

f

If the measuring tool is not used for a long period of

time, the battery must be removed.

The battery can cor-

rode or discharge itself over long periods.

Operation

f

Protect the measuring tool against moisture and direct

sun light.

f

Do not subject the measuring tool to extreme tempera-

tures or variations in temperature. In case of large var-

iations in temperature, allow the measuring tool to ad-

just to the ambient temperature before switching it on.

In case of extreme temperatures or variations in tempera-

ture, the accuracy of the measuring tool and the display in-

dication can be impaired.

f

Use or operation of transmitting systems, such as

WLAN, UMTS, radar, transmitter masts or microwaves,

in the close proximity can influence the measuring

function.

Initial Operation

Switching On and Off

f

Before switching the measuring tool on, make sure that

the sensor area 12 is not moist.

If required, dry the meas-

uring tool using a soft cloth.

f

If the measuring tool was subject to an extreme tem-

perature change, allow it to adjust to the ambient tem-

perature before switching on.

To

switch on

 the measuring tool, press the On/Off button

5

.

To

switch off

 the measuring tool, press the On/Off button

5

again.
When no button on the measuring tool is pressed for approx.

5 minutes and when no objects are detected, the measuring

tool automatically switches off to save the battery.

Switching the Display Illumination On/Off

The display illumination can be switched on/off with display-

illumination button

6

.

Switching the Audio Signal On/Off

The audio signal can be switched on/off with the audio signal

button

7

. When the audio signal is switched off, indication

a

appears on the display.

Digital Detector

GMS 120

Article number

3 601 K81 0..

Maximum scanning depth *

– Ferrous metals

– Non-ferrous metals (copper)

– Live conductors 110 – 230 V

(voltage applied) **

– Wood

120 mm

80 mm

50 mm

38 mm

Automatic switch-off after approx.

5 min

Operating temperature

– 10 ° C ... + 50 ° C

Storage temperature

– 20 ° C ... + 70 ° C

Battery

1 x 9 V 6LR61

Operating life time, approx.

5 h

Weight according to

EPTA-Procedure 01/2003

270 g

Degree of protection

IP 54 (dust and splash

water protected)

* depending on operating mode, material and size of the objects, as well
as material and condition of the base material
** less scanning depth for wires/conductors that are not “live”

f

In terms of accuracy, the measuring result can be inferior in case
of unfavourable surface quality of the base material.

Dr. Egbert Schneider

Senior Vice President

Engineering

Helmut Heinzelmann

Head of Product Certification

PT/ETM9
