10
| English
1 609 929 Y44 | (10.5.11)
Bosch Power Tools
Intended Use
The measuring tool is intended for detecting ferrous and non-
ferrous objects and “live” conductors.
Product Features
The numbering of the product features shown refers to the
illustration of the measuring tool on the graphic page.
1
Illuminated ring
2
Marking hole
3
Display
4
On/Off button
5
Contact pads
6
Sensor area
7
Type plate
8
Battery lid
9
Latch of battery lid
10
Fixture for carrying strap
11
Carrying strap
12
Protective pouch *
* The accessories illustrated or described are not included as
standard delivery.
Display Elements (see figure A)
a
Switched-off audio signal indicator
b
Warning-function indicator
c
Indication of the object type “Non-magnetic metal”
d
Indication of the object type “Magnetic metal”
e
Indication of the object type “Live conductor”
f
Temperature control indicator
g
Battery indicator
h
Main scale
i
Fine scale
Technical Data
Declaration of Conformity
We declare under our sole responsibility that the product
described under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents:
EN 61010-1:2010-10, EN 61326-1:2006-05,
EN 301489-3:2002-08, EN 301489-1:2008-04,
EN 300330-1:2010-02, EN 300330-2:2010-02 according
to the provisions of the directives 2004/108/EC,
1999/5/EC.
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 09.05.2011
Assembly
Inserting/Replacing the Battery
Alkali-manganese batteries are recommended for the meas-
uring tool.
To open the battery lid
8
, press the latch
9
in the direction of
the arrow and fold up the battery lid. Insert the supplied bat-
tery. Pay attention that the polarity is correct, according to
the representation on the inside of the battery lid.
The battery indicator
g
always indicates the current battery
status:
–
Battery fully charged
–
Battery has 2/3 of its capacity or less
–
Battery has 1/3 of its capacity or less
–
Please change battery
f
If the measuring tool is not used for a long period of
time, the battery must be removed.
The battery can cor-
rode or discharge itself over long periods.
Digital Detector
GMS 100 M
Professional
Article number
3 601 K81 100
Maximum scanning depth *
– Ferrous metals
– Non-ferrous metals (copper)
– Live conductors 110 – 230 V
(voltage applied) **
100 mm
80 mm
50 mm
Automatic switch-off after approx.
5 min
Operating temperature
– 10 ° C ... + 45 ° C
Storage temperature
– 20 ° C ... + 70 ° C
Relative air humidity, max.
80 %
* depending on operating mode, material and size of the objects, as well
as material and condition of the base material
** less scanning depth for wires/conductors that are not “live”
f
In terms of accuracy, the measuring result can be inferior in case
of unfavourable surface quality of the base material.
Please observe the article number on the type plate of your measuring
tool. The trade names of the individual measuring tools may vary.
Battery
1 x 9 V 6LR61
Operating life time, approx.
5 h
Degree of protection
IP 54 (dust and splash
water protected)
Weight according to
EPTA-Procedure 01/2003
260 g
Dimensions
(length x width x height)
200 x 86 x 32 mm
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
Digital Detector
GMS 100 M
Professional
* depending on operating mode, material and size of the objects, as well
as material and condition of the base material
** less scanning depth for wires/conductors that are not “live”
f
In terms of accuracy, the measuring result can be inferior in case
of unfavourable surface quality of the base material.
Please observe the article number on the type plate of your measuring
tool. The trade names of the individual measuring tools may vary.
OBJ_BUCH-1418-002.book Page 10 Tuesday, May 10, 2011 8:18 AM
