Universal holder (BM 1)

A)

(20)

Laser target plate

A)

(21)

Protective bag

(22)

Laser goggles

A)

(23)

Tripod (BT 150)

A)

(24)

Telescopic shaft (BT 350)

A)

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical Data

Line laser

GLL 2-10 G

Article number

3 601 K63 P..

Working range

A)

10 m

Levelling accuracy

B)C)

±0.3 mm/m

Self-levelling range

±4°

Levelling time

< 4 s

Operating temperature

−10 °C to +50 °C

Storage temperature

−20 °C to +70 °C

Max. altitude

2000 m

Relative air humidity max.

90 %

Pollution degree according to
IEC 61010-1

2

D)

Laser class

2

Laser type

500−540 nm, < 10 mW

C

6

10

Divergence

50 × 10 mrad (full angle)

Tripod mount

1/4"; 5/8"

Batteries

3 × 1.5 V LR6 (AA)

Operating duration in operating mode

B)

– Cross-line mode

6 h

– Line mode

12 h

Weight according to
EPTA-Procedure 01:2014

0.49 kg

Dimensions (length × width ×
height)

112 × 55 × 106 mm

Protection rating

IP 54 (dust- and splash-

proof)

A) The working range may be reduced by unfavourable environ-

mental conditions (e.g. direct sunlight).

B) At

20–25

 °C

C) The values stated presuppose normal to favourable environ-

mental conditions (e.g. no vibration, no fog, no smoke, no direct
sunlight). Extreme fluctuations in temperature can cause devi-
ations in accuracy.

D) Only non-conductive deposits occur, whereby occasional tem-

porary conductivity caused by condensation is expected.

The serial number

(10)

 on the type plate is used to clearly identify

your measuring tool.

Assembly

Inserting/changing the batteries

It is recommended that you use alkaline manganese batter-
ies to operate the measuring tool.
To open the battery compartment cover

(11)

, press on the

locking mechanism

(12)

 and remove the battery compart-

ment cover. Insert the batteries.
When inserting the batteries, ensure that the polarity is cor-
rect according to the illustration on the inside of the battery
compartment.
If the batteries are running low, the laser lines will gradually
become dimmer.
If the batteries are almost empty, the status indicator

(8)

 will

flash green. The measuring tool can still be operated for ap-
proximately 1 hour after the first flash.
The laser lines will also flash for approximately five seconds
every ten minutes.
If the batteries are empty, the laser lines will flash once be-
fore the measuring tool switches off.
Always replace all the batteries at the same time. Only use
batteries from the same manufacturer and which have the
same capacity.

u

Take the batteries out of the measuring tool when you
are not using it for a prolonged period of time.

 The bat-

teries can corrode and self-discharge during prolonged
storage in the measuring tool.

Working with the RM 1 rotating mount
(see figures A–B)

You can use the rotating mount

(13)

 to rotate the measuring

tool 360° around a central, always visible plumb point. This
enables you to set up the laser lines without having to
change the position of the measuring tool.
Place the measuring tool with the guide groove

(17)

 on the

guide rail

(14)

 of the rotating mount

(13)

 and slide the

measuring tool all the way onto the platform.
To disconnect the measuring tool, pull it off the rotating
mount in the opposite direction.

Rotating mount positioning options:
– Standing on a flat surface,
– Screwed to a vertical surface,
– On metallic ceiling strips using the ceiling clip

(18)

,

– On metallic surfaces using the magnets

(15)

.

Operation

Starting Operation

u

Protect the measuring tool from moisture and direct
sunlight.

u

Do not expose the measuring tool to any extreme tem-
peratures or fluctuations in temperature.

 For example,

do not leave it in a car for extended periods of time. If it
has been subjected to significant fluctuations in temper-
