Eng
SVEN Power Pro
(Ill) OVLD/ CHECK ВАТТ LED :
During an overload operation, the UPS will emit a loud tone and this LED stays on indicating an overload occurs See the Installation
section 6 to recover the UPS from overload operation. Overload indication!
When the battery goes bad, the UPS will emit four short beeps every 3 sees and this LED blinks indicating the battery is no use and
must be replaced. Battery replacement indication!
(1) IINPUT CIRCUIT BREAKER:
The UPS will trip the breaker when loads exceed the UPS’s capacity The resettable plugger extend when tripped
(2) AC INPUT SOCKET:
One standard IEC 320 male socket Use an input line cord to connect UPS
to the utility
(3) OUTPUT SOCKET:
Standard reverse female IEC for 200V series Use an output line cord to connect your equipment to the UPS See the section of speciJ
fications for the numbers of sockets
(4) RS232 PORT:
The UPS's RS232 port is the means by which your UPS communicates with a computer system There are two computer port connecJ
tion. Windows NT protocol and standard RS232 protocol, supported by the UPS Check your dealer for various operating system UPS
monitoring support.
Note: This connection is optional and not needed to use the UPS. The UPS works properly without a connection.
(5) 4 DIP{SWITCHES:
The switches are set to the default position as supplied from the factory The setting of switch 2 3 & 4 must match your local voltage
and frequency source Check your dealer for the appropriate setting All the optional settings are listed as follows
The switch 1 disables the setting for the power saving feature When operating UPS with no equipment load during a utility power outJ
age the UPS will emit two beeps once five sees then shut itself down to save battery energy Power saving’
Switch 1
Power Saving Feature
on
disable
off
enable
The Switch 2 & 3 control the setting for the nominal input voltage Changing the setting, you may shift all switching voltages [like high
and low input voltage limit or booster and buck (optional) for onJline operation] up to + or J 40V to meet special power need in comJ
monJapplication.
Switch 2
Switch 3
Power Source Volt
on
on
200 V
on
off
220 V
off
on
230 V
off
off
240 V
The switch 4 controls the setting for the input power frequency default.
Switch 4
Power Source Frequency
on
50 Hz
off
60 Hz
(6) TELEPHONE/NETWORK SURGE SUPPRESSION :
The RJ45/11 module connectors are used for 10 BaseJT network/single line telephone surge protection.
Note: This connection is optional and not needed to use the UPS. The UPS works properly without a connection.
21
