33

EN

KEOR SP

4.4

Shutdown

1. Press and hold the ON/OFF button until the led bar turns off.

2. The UPS stops powering the outlets.

3. Unplug the UPS from the mains power supply socket.

4.5

LED bar and Alarm Indicators

LED BAR

ALARM

UPS STATUS

Green

Yellow

Red

4 LEDs

steady

-

-

Off

The UPS is operating in normal mode

-

4 LEDs

steady

-

1 beep every

30 seconds

UPS operating in battery mode

with battery status 100%-75%

-

3 LEDs

steady

-

2 beeps every

30 seconds

UPS operating in battery mode

with battery status 75%-50%

-

2 LEDs

steady

-

3 beeps every

15 seconds

UPS operating in battery mode

with battery status 50%-25%

-

1 LED

steady

-

4 beeps every

15 seconds

UPS operating in battery mode

with battery status 25%-10%

-

1 LED

blinking

-

Intermittent

UPS operating in battery mode

with battery status <10%

4 LEDs

blinking

-

-

Intermittent

Overload in normal mode

-

4 LEDs

steady

Continuously

sounding

UPS shutdown due

to prolonged overload

-

4 LEDs

rolling

-

Off

Battery service

4 LEDs

steady

-

-

1 beep every

3 seconds

Overtemperature

-

-

4 LEDs

steady

Continuously

sounding

UPS fault (other than overload)
