SVEN GC-W800 - Инструкция по эксплуатации - Страница 6

ENG

6

Game Racing Wheel

Reassign button function

1. Press SHARE/9/View + OPTIONS/10/Menu, hold for 3 seconds until the green LED lights up.

2. Press the button with the function you want to assign to another button, the green LED will

start flashing.

3. Press the programmable button to which you want to save the new function, the LED switch

-

es to red and stops flashing. The function is installed.

Setting the default button function

1. Press SHARE/9/View + OPTIONS/10/Menu, hold for 3 seconds until the green LED lights up.

2.  Press  the  button  with  the  function  you  want  to  reset  by  default,  the  green  LED  will  start

flashing.

3. Press the same button again. The LED will turn red and stop flashing. The function on the but

-

ton is set by default.

Reset all previously installed settings

1. Press SHARE/9/View + OPTIONS/10/Menu, hold for 3 seconds until the green LED lights up.

2. Press OPTIONS/10/Menu hold for 4 seconds until the red LED lights up.

Attention:  By  disconnecting  the  steering  wheel  from  USB,  all  previously  configured  steering

functions will be reset by default.

Pedal programming as Y-axis

1. Press SHARE/9/View + OPTIONS/10/Menu, hold for 3 seconds until the green LED lights up.

2.  Press  LEFT  on  D-Pad.  The  LED  will  turn  red  and  stop  flashing.  The  pedals  are  programmed

as a function of Y.

Programming paddle shifters L-Wing/brake and R-Wing/Accelerator as Y-axis

1. Press SHARE/9/View + OPTIONS/10/Menu, hold for 3 seconds until the green LED lights up.

2.  Press  RIGHT  on  D-Pad.  The  green  LED  will  turn  red  and  stop  flashing.  Paddle  shifters  pro

-

grammed as a function of Y.

Adjustable steering sensitivity

The setting allows you to set three levels of sensitivity steering.

1. Press SHARE/9/View + OPTIONS/10/Menu, hold for 3 seconds until the green LED lights up.

2. Press SHARE/9/View once again, the LED flashes, displaying the current sensitivity.

3. Press SHARE/9/View the third time to select the level of sensitivity.

The flashing frequency of the LED indicates the sensitivity level of the steering wheel. Low (green

LED blinks slowly), mid level (LED blinks more often), and high (green LED blinks fast).

4.  Press  the  button  UP  on  D-Pad  to  confirm  the  sensitivity  setting  and  exit.  The  LED  will  stop

flashing.

9. WHEEL CONNECTING TO DIFFERENT DEVICES

Use of a wheel together with the PS3 console

1.  Connect  the  pedals  to  the  steering  wheel,  connect  the  steering  wheel  to  the  console  using

a  USB cable.

2. Power on the console.

3. After the LED turns red, the connection is established. Then the wheel can be configured (see

description above) or start the game.

4. During the game, a short press on the MODE button allows you to enter the XBM window,

a long (long hold), allows you to get into the controller's setup menu.

Use of a wheel together with the PS4 console

1. Connect the pedals to the steering wheel, connect the steering wheel to the console using

a USB cable.
