Vestfrost VF 473 EB - Инструкция по эксплуатации - Страница 45

EN -44-

Chiller Shelf

Keeping food in the Chiller compartment instead of

the freezer or refrigerator compartment allows food to

retain freshness and flavour longer, while preserving its

fresh appearance. When the chiller tray becomes dirty,

remove it and wash it with water.
(Water freezes at 0°C, but foods containing salt or sugar

freeze at temperatures lower than that)
Normally the chiller compartment is used to store raw

fish, lightly pickled food, rice, etc...

Do not put foods you want to freeze or ice trays onto the chiller shelf.

Removing the Chiller shelf

•

Pull the chiller shelf towards you by sliding it on

the rails.

•

Pull the chiller shelf up from the rail and remove it

from the fridge.

After the chiller shelf is removed, up to 20kg  of food can

be placed in the fridge.

Fresh dial

When the humidity controller is in the closed position, it allows fresh fruit and vegetables to

be stored for longer.
If the crisper is completely full, open the fresh dial located in front of the crisper. This allows

the air in the crisper and humidity rate to be

controlled and the storage life of the food in the

crisper will be increased.
If you see any condensation on the glass shelf,

the humidity control should be set in the open

position.

Adjustable door shelf

Six  different  height  adjustments  can  be  made  to

provide storage areas that you need by adjustable

door shelf .

To change the position of adjustable door

shelf;

Hold the bottom of the shelf and pull the buttons

on the side of the door shelf direction of arrow (Fig.1).

Position door shelf the height you need by moving up and down. After you get the position

that you want the door shelf, release the buttons on the side of the door shelf (Fig.2) Before

releasing the door shelf, move up down and make sure the door shelf is fixed.

Note:

 Before moving door shelf is loaded, you must hold the shelf by supporting the bottom.

Otherwise, door shelf could fall off the rails due to the weight. So damage may occur on the

door shelf or rails.

(In some models)

Fig.1

Fig.2
