51

4. TROUBLESHOOTING

4-1-4) Restoration of Previous Settings upon Instant Power Outage

1)  If the Display Panel is initialized by the instant power outage, it will cause customer inquiries.

To prevent this, when the power is restored, the previous settings will be restored or reset based on the
inside temperature of the Freezer Compartment.

2)  Upon the initial power on, it checks its Freezer temperature. When it is lower than +10℃, it is to be

considered as an instant power failure and it brings back all its previous operation functions (such as Power
Freeze, Vacation, Fridge, Freezer,Cool Select Zone, etc) related to the panel display.

3)  When it is higher than +10℃, it is to be considered as a long-period power failure and it will initialize the

panel display. (Freezer : Automatically set to -19℃

→

 MID, Fridge : Automatically set to 3℃

→

 MID)

4-1-5) Demo Mode Function for Store Display

1)  During the Normal Operation, press the Freezer + Fridge buttons for 7 seconds.

Then, the "2℃, 3℃ and 5℃" Fridge temperature LEDs and the "-17℃, -19℃ and -21℃" Freezer temperature
LEDs on the Display Panel will blink at the interval of 0.5 seconds for 3 seconds.

2)  At this time, release the Freezer + Fridge buttons and press the Freezer button (it sends out "Ding Dong"

sound.) Then, it shifts to the Demo mode.

3)  When the unit is in Demo Mode, all the functions including the Display Panel works normal. But, the

Compressor does not operate.

4)  To cancel the Demo Mode, press the same buttons for 7 seconds as you enter into the Demo Mode or turn off its power.
5)  Also, when the Freezer or Fridge room temperature goes over 65℃ during the Demo Mode, it will go back to

the normal cooling operation.

①

②

①

②

①

  Press the Freezer + Fridge buttons for 7 seconds at the same time.

Then, the Display LEDs will blink for 3 seconds. At this time, release the buttons

②

 and, press the Freezer button once.
