If the door cannot be opened right after having been closed, due

to vacuum, please wait about 2 minutes until pressure returns to

normal.

CAUTION

Risk of injury due to broken glass!

Bottles and cans containing drinks may burst when being frozen.

This applies particularly to sparkling drinks.

u

Do not freeze bottles and cans containing drinks!

w

The  freezer  temperature  drops,  the  appliance  operates  with

the maximum refrigerating capacity.

u

Place wrapped food straight on the shelves and, once frozen,

put it into the drawers.

In order that the food is rapidly frozen through to the core, do not

exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg

- Meat up to 2.5 kg

u

Pack  the  food  in  portions  in  freezer  bags,  reusable  plastic,

metal or aluminium containers.

5.4 Thawing food

- at room temperature

- in a microwave oven

- in a conventional or fan oven

u

Food  once  thawed  should  be  re-frozen  only  in  exceptional

cases.

5.5 Setting the temperature

Temperature setting to be recommended: -18 °C
The  temperature  can  be  changed  continuously.  Once  the

-32 °C setting is reached, it starts again with -15 °C.

u

To  access  temperature  adjustment:  press  setting  button

Fig. 3 (2) once.

u

Press the setting button

 Fig. 3 (2) the number of times needed

until the required temperature shines in the LED display.

Note

u

Long pressing of the setting button sets a slightly colder value

within  a  small  temperature  range  (e.g.:  between  -15  °C  and

-18 °C) but it is not visible in the display.

5.6 SuperFrost

With  this  function  you  can  freeze  fresh  food  quickly  through  to

the  core.  The  appliance  operates  with  maximum  refrigeration.

The noise of the refrigeration unit may be temporarily louder as

a result.
The maximum amount of fresh food which can be frozen in 24 h

is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".  This  amount  varies  according  to  the  model  and  climate

rating.

5.6.1 Freezing with SuperFrost

You do not have to activate SuperFrost in the following cases:
- when placing frozen food in the freezer

- when freezing up to about 2 kg fresh food daily

u

Briefly press the SuperFrost button

 Fig. 3 (4).

w

The SuperFrost button shines.

w

The  freezer  temperature  drops,  the  appliance  operates  with

the maximum refrigerating capacity.

In case of a small amount of food to be frozen:

u

wait about 6 h.

u

Place the fresh food in the top drawers.

In case of the maximum amount of food to be frozen (see type

plate):

u

wait about 24 h.

w

SuperFrost is automatically deactivated after about 65 h.

w

The SuperFrost button is dark.

w

The  appliance  continues  to  operate  in  the  energy-saving,

normal mode.

5.7 Drawers

Note

The energy consumption increases and the cooling performance

decreases if there is insufficient ventilation.

For appliances with NoFrost:

u

Leave the bottom drawer in the appliance!

u

Always keep the air slits of the fan free at the rear wall!

u

To store frozen food directly on the shelves: pull the drawer

forwards and lift it out.

5.8 Shelves

u

To remove the shelf: lift up at the front and

pull out.

u

To put the shelf back: simply push in as far

as it will go.

5.9 VarioSpace

Apart from being able to remove the

drawers,  you  can  also  remove  the

shelves,  creating  space  for  large

items  of  frozen  food.  Poultry,  meat,

large pieces of game and high bakery

products can be frozen in one piece

and prepared.

u

The  maximum  weight  load  is  15  kg  for  the  top  drawer  and

25 kg for each of the other drawers and shelves.

5.10 Information system

Fig. 9

(1) Ready-made meals, ice

cream

(4) Sausages, bread

(2) Pork, fish

(5) Game, mushrooms

(3) Fruit, vegetables

(6) Poultry, beef/veal

The figures indicate the storage time in months for several types

of frozen food in each case. Storage times given are guide times.

Control

7
