WARNING

Fire hazard and danger of damage!

u

Do  not  place  appliances  emitting  heat  e.g.  microwaves,

toasters etc. on the appliance!

WARNING

Fire hazard and risk of damage due to blocked ventilation grille!

u

Always keep the ventilation grille free. Always ensure that the

appliance is properly ventilated.

u

Detach the connecting cable from the rear of the appliance,

removing  the  cable  holder  at  the  same  time  because  other-

wise there will be vibratory noise!

u

Remove the protective film from the decorative trims.

u

Remove all transit supports.

u

Dispose of packaging material (see 4.5) .

NOTICE

Risk of damage due to condensate!

u

Do not install the appliance directly alongside a further refrig-

erator/freezer.

u

Align the appliance so that it stands

firmly and on a level by applying the

accompanying  spanner  to  the

adjustable-height  feet  (A)  and

using a spirit level.

If the appliance is installed in a very damp environment, conden-

sate may form on the outside of the appliance.

u

Always see to good ventilation at the installation site.

4.5 Disposing of packaging

WARNING

Danger of suffocation due to packing material and plastic film!

u

Do not allow children to play with packing material.

The packaging is made of recyclable materials:

-

corrugated board/cardboard

-

EPS moulded parts

-

polythene bags and sheets

-

polypropylene straps

u

Take the packaging material to an official collecting point.

4.6 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The type of current (alternating current) and voltage at the instal-

lation site have to conform with the data on the type plate  (see

Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.
It must be easily accessible so that the appliance can

be quickly disconnected from the supply in an emer-

gency.

u

Check the electrical connection.

u

Clean the appliance  (see 6.2) .

u

Plug in the power plug.

4.7 Switching on the appliance

u

Press On/Off button

 Fig. 3 (1).

w

The  appliance  is  switched  on.  The  temperature  display  and

the alarm button flash until the temperature is sufficiently cold.

5 Control

5.1 Door alarm

If the door is open longer then 60 s, the audible alarm sounds.
The  audible  alarm  is  automatically  silenced  when  the  door  is

closed.

5.1.1 Muting the door alarm

The  audible  alarm  can  be  muted  when  the  door  is  open.  The

sound switch-off function is active as long as the door is left open.

u

Press alarm button

 Fig. 3 (5).

w

The door alarm is silenced.

5.2 Temperature alarm

The audible alarm sounds if the freezer temperature is not cold

enough.
The alarm button flashes at the same time.

The cause of the temperature being too high may be:

-

warm fresh food was placed inside

-

too much warm ambient air flowed in when rearranging and

removing food

-

power failure for some time

-

the appliance is faulty

The  audible  alarm  is  automatically  silenced,  the  alarm  button

Fig.  3  (5)  goes  out  and  the  temperature  display  stops  flashing

when the temperature is sufficiently cold again.
If the alarm status persists:  (see Malfunction).

Note

Food may be spoilt if the temperature is not cold enough.

u

Check the quality of the food. Do not consume spoiled food.

5.2.1 Muting the temperature alarm

The audible alarm can be muted. When the temperature is suffi-

ciently cold again, the alarm function is active again.

u

Press alarm button

 Fig. 3 (5).

w

The audible alarm is silenced.

5.3 Freezing food

The maximum weight of fresh food which can be frozen within 24

h  is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".
The maximum weight load is 15 kg for the top drawer and 25 kg

for each of the other drawers and shelves.
