Saving energy

-  Always ensure good ventilation. Do not cover ventilation

  openings or grille.

-  Do not place appliance in areas of direct sunlight or next

to a stove, heater or similar object.

-  The energy consumption depends on the installation

conditions, e.g. the ambient temperature.

-  Keep the time the appliance is open to a minimum.

-  The lower the temperature setting, the higher the power

  consumption.

-  Store food logically.

-  Ensure that all food is well packed and covered for stor-

age. This will prevent frost from forming.

-  Remove food as needed in order that it does not warm

too much.

-  First cool warm food to room temperature before storing it.

-  If there is a thick layer of frost in the

appliance: defrost the appliance.

Accumulated dust increases the

energy consumption:

-  Once a year, dust the refrigerating

  unit together with the metal grille

of the heat exchanger at the back

of the appliance.

Switching the appliance on and off

You are recommended to clean the appliance before

switching it on for the first time (see "

Cleaning"). Switch

the appliance on 4 hours before loading it with frozen food

for the first time.

Off: Using a coin, turn the arrow on the temperature con-

trol

1

 to a setting between "1" und "".

– The green ON-LED

2

is lit.

– The red warning-LED

3

twinkle up.

– The red warning-LED  is unlit as soon as the freezer

compartment is cold enough (see "Red warning-LED").

To switch the appliance off: Turn the arrow on the tem-

perature control

1

 to "0". The visual control-LED are unlit.

Setting the temperature

Setting "1" = lowest cooling setting, warm

Setting "6" = highest cooling setting, cold

•

We recommend a

medium setting.

•

If you are storing frozen food and wish to ensure that the

low freezing temperature is maintained, we recommend
setting the temperature control to between "4" and "".

• For long-term storage of frozen food a temperature of at

least -18°C is recommended. Remember that the tem-

perature depends on the ambient temperature (location

of appliance), the number of times the door is opened

and how much frozen food is stored. The setting should

be adjusted accordingly if necessary.

Dimensions

(mm)

G 1221

Connecting to the mains

Power supply (a.c.) and voltage at the operating point must

comply with the details on the type plate which is located on the

left-hand  inside  wall,  next  to  the  top  freezer  drawer. The  socket

must be fused with a 10 A fuse or higher. The socket should be

easily accessible and not directly behind the appliance.

•

Do not connect the appliance to the supply with other equip-

ment using a distribution outlet - risk of overheating.

•

Connect the appliance through a properly earthed plug

and socket.

Setting up

•  The floor on which the appliance stands should be horizon-

tal and level. To compensate for any unevenness, adjust the

height of the feet with an open-ended wrench.

•  Always position the appliance directly up against the wall.

•  The ventilation grilles should not be obstructed.

•  Condensation may form on the outside of the refrigerator/

freezer during periods of high humidity. Constant ventilation of

the installation site is recommend.

•  Keep burning candles, lamps and other items with naked

flames away from the appliance so that they do not set the

appliance on fire.

•  In order to avoid the risk of fire, do not place any burning candles,

lamps or other objects with open flames on the refrigerator/freezer.

•  Standard EN 378 specifies that the room in which you install

your appliance must have a volume of 1 m

3

 per 8 g of R 00a

refrigerant used in the appliance, so as to avoid the formation of

inflammable gas/air mixtures in the room where the appliance is

located in the event of a leak in the refrigerant circuit.

   The quantity of refrigerant used in your appliance is indicated

   on the type plate on the inside of the appliance.

•  Fire hazard due to dampness!

  If live parts or the mains lead become damp this may cause

short circuits.

-  The appliance is designed for use in enclosed areas. Do not

operate the appliance outdoors or in areas where it is exposed

to splash water or damp conditions.

•  CAUTION! Risk of injury and danger of damage as a result of

incorrect transport!

-  Transport the appliance in a packed condition.

-  Transport the appliance upright.

-  Do not transport the appliance without assistance.

•

The appliance may be moved only when it is empty.

The red visual warning LED

The red warning-LED

3

lits up if the temperature in the

freezer compartment is not cold enough, i.e. when the

temperature is above -8°C.

If the red warning-LED comes on during normal opera-

tion, check:

– whether there has been a lengthy interruption to the

power supply; check the quality of the frozen food and

prepare for consumption if necessary,

– whether the door is properly shut,

– whether fresh food has recently been inserted.
If none of the above apply, consult your nearest customer

service department as soon as possible, giving details of

the

type of appliance, index and service number.

A

      h         a         g         e         e'         d         c         c'

    851     553     610     624      653    1129     563      592
