5.7 Freezer compartment

You  can  store  frozen  food,  make  ice  cubes  and  freeze  fresh

food in the freezer compartment.

5.7.1 Freezing food

The  rating  plate  indicates  the  maximum  quantity  of  fresh  food

you  can  freeze  within  24  hours  (see  Appliance  at  a  glance)

under "Freezing capacity ... kg/24h".
The maximum load of frozen food for the drawers is 25 kg each

and for the shelves 35 kg each.

CAUTION

Risk of injury due to broken glass!

Bottles  and  cans  containing  drinks  may  burst  when  being

frozen. This applies particularly to sparkling drinks.

u

Do not freeze bottles and cans containing drinks!

In  order  that  the  food  is  rapidly  frozen  through  to  the  core,  do

not exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg

- Meat up to 2.5 kg

u

Pack  the  food  in  portions  in  freezer  bags,  reusable  plastic,

metal or aluminium containers.

5.7.2 Thawing food

- in the refrigerator compartment

- at room temperature

- in a microwave oven

- in a conventional or fan oven

u

Food  once  thawed  should  be  re-frozen  only  in  exceptional

cases.

5.7.3 Setting the temperature in the freezer

compartment

The appliance is pre-set for normal operation.
The  temperature  can  be  set  between  -16  °C   and  -26  °C,  the

recommended temperature is -18 °C.

u

To  set  the  temperature  higher:  press  Up  button,  freezer

compartment

 Fig. 3 (15).

u

To  set  the  temperature  lower:  press  Down  button,  freezer

compartment

 Fig. 3 (16).

w

When the button is pressed the first time, the previous value

is  indicated  in  the  temperature  display  of  the  freezer

compartment.

u

To  change  the  temperature  in  1  °C  steps:  briefly  press  the

button.

-or-

u

To  change  the  temperature  continuously:  hold  down  the

button.

w

The value is displayed flashing during the setting operation.

w

The  actual  temperature  is  displayed  about  5  s  after  the  last

press of a button. The temperature slowly adjusts to the new

value.

5.7.4 SuperFrost

With  this  function  you  can  freeze  fresh  food  quickly  through  to

the  core.  The  appliance  operates  with  maximum  refrigeration.

The noise of the refrigeration unit may be temporarily louder as

a result.
The  maximum  amount  of  fresh  food  which  can  be  frozen  in  24

h  is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".  This  amount  varies  according  to  the  model  and  climate

rating.
You do not have to activate SuperFrost in the following cases:

-

when placing frozen food in the freezer

-

when freezing up to about 2 kg fresh food daily

Freezing with SuperFrost

u

Briefly press the SuperFrost button

 Fig. 3 (18) once.

w

The SuperFrost symbol

 Fig. 3 (13) shines.

w

The  freezer  temperature  drops,  the  appliance  operates  with

maximum refrigerating performance.

For a small amount of food:

u

wait about 6 h.

u

Place the fresh food in the top drawers.

For the maximum amount of food:

u

wait about 24 h.

u

Place  wrapped  food  straight  on  the  shelves  and,  once

frozen, put it into the drawers.

w

SuperFrost  is  automatically  deactivated.  Depending  on  the

quantity  placed  inside,  after  30  h  at  the  earliest,  65  h  at  the

latest.

w

Freezing is concluded.

w

The SuperFrost symbol

 Fig. 3 (13) goes out.

w

The  appliance  continues  to  operate  in  the  energy-saving,

normal mode.

5.7.5 Drawers

Note

The  energy  consumption  increases  and  the  cooling  perform-

ance decreases if there is insufficient ventilation.

For appliances with NoFrost:

u

Leave the bottom drawer in the appliance!

u

Always keep the air slits of the fan free at the rear wall!

u

To store frozen food directly on the shelves: pull the drawer

forwards and lift it out.

5.7.6 Shelves

u

To  remove  the  shelf:  lift  up  at  the  front

and pull out.

u

To  put  the  shelf  back:  simply  push  in  as

far as it will go.

5.7.7 VarioSpace

Apart  from  being  able  to  remove

the  drawers,  you  can  also

remove  the  shelves,  creating

space  for  large  items  of  frozen

food. Poultry, meat, large pieces

of  game  and  high  bakery  prod-

ucts  can  be  frozen  in  one  piece

and prepared.

u

The  maximum  load  of  frozen

food  for  the  drawers  is  25  kg

each  and  for  the  shelves

35 kg each.

Control

13
