ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USER GUIDE

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USER GUIDE

ХОЛОДИЛЬНИК

 REFRIGERATOR-FREEZER

ХОЛОДИЛЬНИК

 REFRIGERATOR-FREEZER

Key

A.SET: gear setting key
Display screen

1

Gear 1

2

Gear 2

3

Gear 3

4

Gear 4

5

Gear 5

Display

For the first power-on, the display screen (including the key light) will be displayed in

full for 3s, and then the gear in the middle displays the state of running

Display of normal running

•

On  the  occurrence  of  a  failure,  the  corresponding  LED  light  will  give  a  combined
display of failure code (loop display);

•

Where  there  is  no  failure,  the  LED  light  will  display  the  current  running  gear  of  the
refrigerator.

Gear setting

The gear will be changed once every time when you press the key SET. Then, the

refrigerator will run under the setting value after 15s.

—>     —>     —>     —>     —>       —>
Gear 1

Fast cool function

Enter: Circulating modulation rapid cooling mode.
Operate: Indicator of rapid cooling lights up, and the refrigerator operates at 2°C.

Exit: 1. Operate 150 min under the rapid cooling mode
2. Temperature adjustment can exit from the rapid cooling mode

Temperature control of freezing chamber

The  freezing  temperature  is  relatively  low  in  “

COLDER

”  position,  while  the  freezing

temperature is relatively high in “

COLD

” position, thus, “

NORMAL

” position is generally

used.

When ambient temperature is high in summer, the temperature shall be in the range

from  “

NORMAL

”  to  “

COLD

”.  If  the  ambient  temperature  is  above  35°C,  then  “COLD”

position shall prevail.

When ambient temperature is low in winter, the temperature shall be in the range from

“

NORMAL

”  to  “

COLDER

”.  If  the  ambient  temperature  is  below  10°C,  then  “

COLDER

”

position shall prevail.

4.2  Noise inside the unit!

 You may notice

that your unit makes some unusual noises. Most of these

are perfectly normal, but you should be aware of them!

These  noises  are  caused  by  the  circulation  of  the  refrigerant  liquid  in  the  cooling

system. It has become more pronounced since the introduction of CFC free gases. This
is  not  a  fault  and  will  not  affect  the  performance  of  your  unit.  This  is  the  compressor
motor working, as it pumps the refrigerant around the system.

4.3  Tips for keeping food in the unit

•

Cooked meats/fishes should always be stored on a shelf above raw meats/fishes to
avoid bacterial transfer. Keep raw meats/fishes in a container which is large enough
to collect juices and cover it properly. Place the container on the lowest shelf.

•

Leave space around your food, to allow air to circulate inside the unit. Ensure all parts
of the unit are kept cool.

•

To prevent transfer of favours and drying out, pack or cover the food separately. Fruit
and vegetables do not need to be wrapped.

•

Always  let  pre-cooked  food  cool  down  before  you  put  in  the  unit.  This  will  help  to
maintain the internal temperature of the unit.

•

To prevent cold air escaping from the unit, try to limit the number of times you open
the door. We recommend that you only open the door when you need to put food in
or take food out.

4.4  Change the Light Bulb

External Display

for KF-NF310WD

KF-NF310XD

SET

TEMPERATURE

FAST COOL

2

4

6

3

8

Internal Display

for KF-NF300W

KF-NF300X
