ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USER GUIDE

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ • USER GUIDE

ХОЛОДИЛЬНИК

 REFRIGERATOR-FREEZER

ХОЛОДИЛЬНИК

 REFRIGERATOR-FREEZER

Electrical Connection

•  Improper  use  of  the  grounded  plug  can  result  in  the  risk  of  electrical  shock.  If  the

power cord is damaged, have it replaced by an authorized service center.

•  This refrigerator should be properly grounded for your safety. The power cord of this

refrigerator  is  equipped  with  a  three-prong  plug  which  mates  with  standard  three
prong wall outlets to minimize the possibility of electrical shock.

•  Do  not,  under  any  circumstances,  cut  or  remove  the  third  ground  prong  from  the

power cord supplied.

•  This  refrigerator  requires  a  standard  220-240  V  A.C.  ~/50  Hz  electrical  outlet  with

three-prong ground.

•  This refrigerator is not designed to be used with an inverter.
•  The cord should be secured behind the refrigerator and not left exposed or dangling

to prevent accidental injury.

•  Never unplug the refrigerator by pulling the power cord.  Always grip the plug firmly

and pull straight out from the receptacle.

•  Do not use an extension cord with this appliance. If the power cord is too short, have

a qualified electrician or service technician install an outlet near the appliance. Use of
an extension cord can negatively affect the performance of the unit.

 Before Plugging in!

You must check that you have a socket which is

compatible with the plug supplied with the unit.

 Before switching on!

Do not turn on until two hours after moving the unit.

 DO NOT SWITCH ON

UNTIL FOUR HOURS AFTER MOVING THE FRIDGE/

FREEZER. The coolant fluid needs time to settle. If the appliance is switched off
at any time, wait 30 minutes before switching back on to allow the coolant fluid
to settle.

Interior Accessories

Various glass or plastic storage shelves are included with your appliance — different

models have different combinations.

You should always slide one of the full size glass storage shelves into the lowest set

of  guides,  above  the  fruit  and  vegetable  containers,  and  keep  it  in  this  position.  To  do
this,  pull  the  storage  shelf  forward  until  it  can  be  swiveled  upwards  or  downwards  and
removed.

 Note:

Please do the same in reverse to insert the shelf at a different height.

In order to make the most of the volume of the fresh food storage compartment and

frozen-food storage compartment, the user can remove one or more shelves, drawers,
out of the appliance, according to your daily use.

START

1.  Before  connecting  the  Fridge/Freezer  to  the  mains  supply  position.  The  thermostat

control dial is located inside the Fridge compartment.

2. Turn the thermostat knob to the “3” position and turn on the electricity. The compressor

and the light inside the refrigerator will begin to work.

3. Wait 24 hours before placing food into the Fridge/Freezer, the temperature inside your

Fridge/Freezer will then be cool enough to chill and freeze foods sufficiently.

Adjusting the temperature

1. The temperature in the refrigerator and freezer compartment is controlled by the
temperature controller installed on the inside wall of the refrigerator compartment.
We strongly recommend you use a freezer thermostat to check that the temperature
is below -18 centigrade before loading any food. This can take 2-3 hours.
2. The marks on the knob are the temperature grades, NOT the exact degrees of
temperature. “0” is “OFF” AND “7” represents the lowest temperature.
3. Please start with the knob set to position “4”. Use a suitable thermometer to check
the temperature after two hours. The refrigerator temperature should be set between
+2°C and +5°C and the freezer will vary between -10 and -18 degrees centigrade
over a typical cycle. To reduce the refrigerator temperature turns the knob towards”6”
and check after one hour.

NOTE:

The Fridge/Freezer may not operate at the correct temperature if it is in a

particularly hot or cold room or is you open the Fridge/Freezer door too often.

Super Freezing

1.  Quick  freezing  allows  moisture  inside  foodstuffs  to  form  fine  ice-crystals  which

prevent the cell membrane from being damaged and the cytoplasm being lost when
unfreezing, thus the original freshness and nutrition constituent of foodstuffs can be
retained.

2. Fresh meal and fish to be stored for long time must be done by quick freezing. To quick

freeze turn the temperature knob to setting “6” before adding food.

NOTE:

the maximum allowable capacity is 3KG at a time.

3. After quick freezing, turn the knob back to the original position (Normally time for quick

freezing shall not exceed 4 hours).

Tips for keeping food perfect in the Fridge

Take extra care with meat and fish

Cooked meats should always be stored on a shelf above raw meats to avoid bacterial

transfer. Keep raw meats on a plate which is large enough to collect juices and cover it
with cling film or foil.

Leave space around food

This allows cold air to circulate around the Fridge, ensuring all parts of the Fridge are

kept cool.
