10

Oper

a

tion

Freezer

Freezer Dividers

The freezer dividers separate the freezer into sections for easy food organization.
Each drawer has two dividers which are removable but not interchangeable.
Upper basket dividers are not adjustable.  Lower basket dividers are adjustable.

WARNING

If the lower freezer basket dividers are removed, there is enough space for children to crawl
inside. To prevent accidental child entrapment,

DO NOT

allow children to play inside drawer.

Automatic Ice Maker

The ice maker is located above the  upper freezer drawer on the left hand side.

After the refrigerator reaches normal temperature, the ice maker fi lls with water and
begins operating. Under normal conditions, the ice maker will produce seven to nine
batches of ice per 24 hour period.

Note: Allow 24 to 48 hours after installation before looking for ice in your ice drawer.
You should discard the fi rst three full drawers of ice produced by your refrigerator,
and should also throw out the fi rst drawer full of ice your refrigerator produces after
extended periods of non-use.

During ice production, the ice maker arm raises and lowers. When the ice bin is full, the
ice maker arm automatically turns the ice maker off . To manually stop ice production,
raise the ice maker arm. You will hear a defi nite click when you have the arm in the right
position. The ice maker won’t produce any more ice until you lower the ice maker arm.

CAUTION

   To avoid damage to ice maker, observe the following:
•

DO NOT

 force ice maker arm down or up past stop position.

•

DO NOT

 place or store anything in ice bucket.

 On
Position

Ice Maker
Arm

Off
Position

Ice Bin Removal

To remove the ice bin, pull top freezer drawer open.  Raise
handles on both sides and pull up.  When replacing the ice
bin, lower handles before closing drawer.

2

1

To remove dividers, push rear divider toward back of drawer until front tab
releases from front drawer panel.  Rotate slightly and pull up.  To replace, place
rear tab in back of drawer, push and lower front of divider into slot on front panel

Rear Tab

Handles down

Handles up

Freezer Drawers

Both freezer drawers are removable.

Pull drawer all the way out.
Remove clip on both sides of drawer.
Lift drawer up and out.

Clip
