6

|

   English

subzero.com

|

   7

Water Dispenser

The water dispenser is located inside the refrigerator on
the left wall. Press a glass against the dispenser to activate
water flow. Water flow will stop when the glass is pulled
away. Refer to the illustration below.

The chilled water reservoir tank holds approximately 1.2 L
of filtered water. It may take several hours to chill the water
to refrigerator temperature during the original fill and after a
large amount of water is dispensed.

To fill the tank, press a glass against the dispenser until
water begins to flow. A safety feature was incorporated into
the dispenser to limit continuous water flow to 60 seconds.
If water does not dispense within 60 seconds, remove the
glass, then reapply to the dispenser until water begins to
flow. Once the tank is full, discard the first few glasses
of water. It may contain impurities from new plumbing
connections.

Ice Maker Operation

To initiate ice production, touch the

 indicator on the

options screen. A single highlighted cube indicates the ice
maker is active. Three highlighted cubes indicate the max
ice feature is active. Max ice increases ice production up to
30% for a 24-hour period. During that period, some com-
ponents may run at a higher speed resulting in a unique
audible tone. This is typical and will revert back after 24
hours or when the ice container is full. To deactivate the ice
maker, touch

 until no cubes are highlighted. After initial

start-up, discard the first few batches of ice. The ice may
contain impurities from new plumbing connections.

If ice is not used regularly it may fuse together. To avoid,
discard ice and allow ice maker to replenish.

The ice maker must be turned off by touching

 when the

ice storage container is removed. The unit is equipped with
a 3-minute delay after the ice container has been removed,
to ensure cubes are not ejected before the ice maker can be
deactivated or ice container is reinstalled.

Sabbath

This appliance is certified by Star-K to meet strict religious
regulations in conjunction with specific instructions found
on www.star-k.org.

For Sabbath mode, from the settings screen, touch

 and

follow instructions on the control panel.

WATER DISPENSER


Water dispenser.

OPERATION

AIR PURIFICATION CARTRIDGE REPLACEMENT

1

   To access the air purification cartridge, grasp the outside

cover from the bottom and rotate upward (top and rotate
downward for drawers). Refer to the illustrations below.

2

   Grasp the black cover from the top and rotate down-

ward. The cartridge will pop out and can be removed.

3

   Remove the new cartridge from packaging and insert

with connector pointing downward.

4

   Once in position, close the black cover. Then rotate the

outside cover downward (upward for drawers).

5

   Once the cartridge has been replaced, follow instructions

on the control panel. The cartridge life cycle will reset for
approximately one year.

Air Purification System

The advanced air purification system of Sub-Zero integrated
models reduces bacteria, odors and ethylene gas, which
causes premature ripening in fruits and vegetables. If your
unit is equipped with an air purification system, the cartridge
has been factory installed and is located on the back wall of
the refrigerator (back of upper drawer for drawer models).

To initiate air purification, touch

 on the options screen.

The cartridge will last approximately one year. ’Change Air
Purifier’ will appear on the control panel when the cartridge
needs to be replaced. Touch ’Snooze’ to delay reminder for
24 hours or until cartridge can be replaced.

AIR PURIFIER LAMP

CONTAINS MERCURY

Manage in accordance with disposal laws.

In the U.S. visit earth911.com or call 800-222-7820.


Air purification cartridge
(column and tall).


Air purification cartridge
(drawers).
