EN

Installation

RH 430, RH 440

16

•

The minimum clearance between the cooling device‘s back and the surrounding
structure should be as follows:

•

The ventilation duct must at least measure 105 mm x the width of the cooling
device.

•

Only the entire cooling unit must project into the ventilation duct as shown.

•

Air passing through the ventilation duct must not be preheated by any source of
heat.

•

The ventilation duct must be kept free from any obstacles. Especially portable
multi socket outlets or portable power supplies, which can get warm, must not
be kept at the rear of the cooling device.

6.1

Fixing the cooling device

➤

Fix the cooling device through its fixing feet as shown (fig.

2

, page 3).

6.2

Changing the decorative plate

➤

Change the decorative plate as shown (fig.

4

to fig.

7

, page 5).

6.3

Mounting the sliding hinge (optional)

You can mount a sliding hinge that allows the cooling device door to be opened at
the same time as the door of the built-in cabinet.

➤

Mount the sliding hinge as shown (fig.

8

, page 6, to fig.

l

, page 9).

6.4

Reversing the door

➤

Reverse the door as shown (fig.

m

to fig.

q

, page 10).

or ...

➤

Reverse a door with a sliding hinge as shown (fig.

o

and fig.

p

, page 10).

No. in

fig.

3

, page 4

Min. distance

2

20 mm

3

105 mm
