15

ENGLISH

WARNING

 Do not install the refrigerator in a damp or wet

■

location as this may cause damage to the insulation

and a leakage. Condensation may also build on the

outer cabinet and cause rust.

1

  Keep adequate ventilation space around the refrigerator.

The figure shows the minimum required space for

•

installing the refrigerator. The measurement condition

of power consumption is conducted under a different

space dimension.

By keeping greater space, the refrigerator may be

•

operated under a less amount of power consumption.

If using the refrigerator in the smaller space dimension

•

than the below figure, it may cause the temperature

rise in the unit, loud noise and failure.

2

  Use the two front adjustable feet, to ensure that the

refrigerator is positioned firmly and flat on the floor.

Before using your refrigerator

Clean the inside parts with a cloth soaked in warm water.

If soapy water is used, wipe it off thoroughly with water.

INSTALLATION

90mm

or more

60mm

or more

60mm

or more

1180 mm

1500 mm

60mm

or more

3

  When right and left doors are not properly aligned, adjust

using the adjustable feet.

NOTE

Position your refrigerator so that the plug is accessible.

•

Keep your refrigerator out of direct sunlight.

•

Do not place next to heat generating appliance.

•

Do not place directly on the ground. Provide suitable stand.

•

To insert the power plug when the door is opened, door alarm

•

sounds but it is not abnormal. This sound stops when closing

the door.

Adjustable foot

When the left door is

raised.

When the right door is

raised.

Lower the foot

at right side.

Lower the foot

at left side.

(Until the adjustable foot on the

other side is slightly off-ground.)

4

  Remove the 4 screws of the cabinet lower part, and

then set the foot cover (supplied inside the refrigerator

compartment) with removed 4 screws.

Screw

(4 screws)

Screw

Foot cover

Free standing type
