16

INSTALLATION

WARNING

Do not install the refrigerator in a damp or wet location

■

as this may cause damage to the insulation and a

leakage. Condensation may also build on the outer

cabinet and cause rust.

1

  Keep adequate ventilation space around the refrigerator.

The figure shows the minimum required space for

•

installing the refrigerator. The measurement condition

of power consumption is conducted under a different

space dimension.
By keeping greater space, the refrigerator may be

•

operated under a less amount of power consumption.
If using the refrigerator in the smaller space dimension

•

than the below figure, it may cause the temperature

rise in the unit, loud noise and failure.

60mm

90mm

1350mm

60mm

60mm

1300mm

Free standing type

2

  Use the two front adjustable feet, to ensure that the

refrigerator is positioned firmly and flat on the floor.

3

  Clip the foot cover (supplied inside the refrigerator

compartment) in position in front of the two adjustable

feet.

NOTE

Position your refrigerator so that the plug is accessible.

•

Keep your refrigerator out of direct sunlight.

•

Do not place next to heat generating appliance.

•

Do not place directly on the ground.

•

Provide suitable stand.

Before using your refrigerator

Clean the inside parts with a cloth soaked in warm water.

If soapy water is used, wipe it off thoroughly with water.

Before transporting

Wipe up water in the evaporating pan.

•

Before wiping up the water, wait more than 1 hour after

pulling out the plug because refrigeration cycle equipment

is extremely hot.

(The evaporating pan is located on the rear of the product.)

NOTE

Do not bend or damage the ductwork located on the inside of

•

the evaporating pan. It may cause failure.

When transporting

The casters allow the refrigerator to move and forth.

•

Carry the refrigerator by holding the handles located on

•

the rear and bottom.

When the door is heavy to open

When one side door is heavy

When the left side is heavy, lower the right side adjustable

•

foot.

(Until the opposite side adjustable foot is slightly off-ground.)

When the right side is heavy, lower the left side adjustable

•

foot.

When both sides are heavy

When the refrigerator is tilted backwards insert a wooden

•

board (with relatively large width), etc. between the rear of

the refrigerator and the floor to adjust the tilting.

or more

or more

or more

Adjustable foot

Foot cover

A wooden board

(with relatively large

width)

Front

Back

Heavy

Adjustable foot

Casters

(4 pcs.)

rear

bottom

or more

Evaporating pan
