11

INSTALLATION

OPERATION

CONTROLLING TEMPERATURES

The refrigerator controls its temperature automatically. However, if needed, adjust the temperature as follows.

   •

If the refrigerator is operated for a long time with
FREEZER TEMP. CONTROL set at 7 (MAX), foods
stored in the refrigerator compartment may also freeze.

   •

If the refrigerator is operated for a long time with
REFRIGERATOR TEMP. CONTROL set at 7 (Coldest),
foods stored in the refrigerator compartment may also
freeze.

   •

Low ambient temperature may cause placed foods to
freeze even if REFRIGERATOR TEMP. CONTROL is
set to 1 (MIN).

HINTS WHEN MAKING ICE

  1.

Do not over fill the Ice cube trays; otherwise the ice
cubes will be joined together when frozen.

  2.

When the ice cubes are
made, turn the lever clock-
wise to empty the ice into
the Ice cube box.

NOTE:

To prevent damage to the Ice cube box, do not make ice in
the Ice cube box or pour oil into it.

  1.

Keep adequate ventilation space
around the refrigerator.

•

The figure shows the minimum

required space for installing the
refrigerator. It differs from the space
in the measurement condition of the
amount of power consumption.

•

It is possible to use the refrigerator

with a less amount of power
consumption by keeping greater
space.

•

If using the refrigerator in the space

below dimension of the figure, it
may cause the temperatures in the
unit to rise, loud noise, and failure.

  2.

Using the two front Adjustable feet,
ensure that the refrigerator is posi-
tioned firmly and level on the floor.

When transporting

 1.

Before transporting, wipe dry

any water in the Evaporating pan
located on the rear.

 2.

Carry the refrigerator by holding

the handles located on the rear
and bottom.

Before using your refrigerator

Clean the inside parts with a cloth
soaked in warm water. If soapy
water is used, wipe it off thoroughly.

NOTE:

   •

Position your refrigerator so that the plug is accessible.

   •

Keep your refrigerator out of direct sunlight.

   •

Do not place next to heat generating appliance.

   •

Do not place directly on the ground. Provide suitable stand.

Foot

Adjustable
foot

cover

60 mm

or more

60 mm

or more

90 mm

or more

1210 mm

1320 mm

7(MAX)

For making ice rapidly or fast freezing.

4(MED)

For normal freezing.

1(MIN)

When frozen food or ice cream is not stored.

Freezer
compartment

7(Coldest)

For keeping foods fresher tasting. When the refrigerator
does not provide sufficient cooling.

4(MED)

For normal operation.

1(MIN)

When the refrigerator provides excessive cooling.

Refrigerator
compartment

Ice cube box

Lever

10
