6

Controlling temperature

Adjustable by turning each knob.

Hybrid cooling panel (Aluminum panel)

The panel is cooled from the rear, thus indirectly cooling

the refrigerator compartment. In this way, food is

refrigerated gently, without exposing it to cold air flow.

Deodorizing unit

Deodorizing catalyst is installed on the routes of cold air.

No operation and cleaning are required.

Hints when making ice

1

Do not over fill the Ice cube trays; otherwise the ice

cubes will be joined together when frozen.

2

SJ-T361R, SJ-T401R

When the ice cubes are made,

turn the lever clockwise to

empty the ice into the Ice cube

box.

SJ-CT361R, SJ-CT401R

When the ice cubes are made,

hold the Ice cube tray upside

down whilst twisting either end

in opposite directions, allowing

the ice cubes to drop out.

NOTE

To prevent damage to the Ice cube

box, do not make ice in the Ice cube box or pour oil into it.

Tube stand

Prevents bottles etc. from falling.

Stick-type food products can also be

stored inside.

Refrigeration reduces the rate of food spoilage. To

maximize the shelf life of perishable food products, ensure

that the food is the freshest possible quality. The following

is a general guide to help promote longer food storage.

•

Ensure all cooked food is wrapped securely or placed in

an airtight container.

•

To minimize moisture loss, fruit and vegetables should

be loosely enclosed in a plastic material e.g. wrap, bags

(do not seal) and place in the fruit and vegetable crisper.

•

Eggs should be stored in the Egg holder.

•

Evenly place the food on the shelves to allow the cooling

air to circulate efficiently.

•

Hot foods should be cooled before storing. Storing hot

foods increases the temperature in the unit and

increases the risk of food spoilage.

•

Do not block the outlet and inlet of the cool air circulating

circuit with foods or containers; otherwise the foods will

not be evenly cooled throughout the refrigerator.

•

Keep the door securely closed.

For best freezing

•

Quality of foods should be fresh.

•

Freeze small quantities of food at a

time to freeze them quickly.

•

Food should be properly stored or

covered and the air should be

removed to seal tightly.

•

Evenly place the food in the freezer.

•

Label bags or containers to keep an

inventory of freezing food.

DESCRIPTION

18

19

14

16
17

1

2

3
4
5

8
9

10

6

7

11

12

13

14

15

16

20

21
22

SJ-T401R

  1. Freezer shelf

  2. Ice cube maker

(SJ-T361R, SJ-T401R)

Ice cube tray

(SJ-CT361R, SJ-CT401R)

  3. Ice cube box

  4. Fresh case & door

  5. Refrigerator light

  6. Freezer temp. control knob

  7. Refrigerator temp. control

knob

  8. Refrigerator shelf

(2 pcs.)

  9. Hybrid cooling panel

(Aluminum panel)

(Only for SJ-T361R, SJ-T401R)

10. Fruit and vegetable shelf

11. Fruit and vegetable crisper

12. Divider

13. Adjustable feet & cover

(2 pcs.)

14. Magnetic door seal

(2 pcs.)

15. Freezer bar

16. Door pocket

(2 pcs.)

17. Refrigerator pocket

18. Egg holder

19. Utility pocket

(2 pcs.)

20. Utility pocket (large)

(Only for SJ-T401R, SJ-CT401R)

•

Do not replace the right and left

position of the utility pocket and

the utility pocket (large).

21. Bottle pocket

22. Tube stand

(Only for SJ-T361R, SJ-T401R)

SJ-CT361R, SJ-CT401R

2

19

SJ-T361R, SJ-CT361R

(for refrigerator)

(for freezer)

Ice cube box

Lever

Ice cube tray

STORING FOOD
