12

EN

Removing the Door

When it is necessary to move the appliance

through a narrow opening, removing the doors is

the recommended procedure.

WARNING

•

Disconnect the power cord, house fuse or

circuit breaker before installing or servicing the

appliance. Failure to follow these instructions

may result in death, fire or electric shock.

If your entrance door is too narrow for the

appliance to pass through, remove the appliance

doors and pass the appliance laterally.

[For both freezer and fridge]

1

Remove the screw of the hinge cover on top of

the appliance by rotating it counterclockwise.

2

While pressing (1) hook of the link of the

electrical connectors, remove the link by

pulling it in both directions.

3

Remove the hinge lever by tapping the end of

it toward the outside edge of the cabinet.

CAUTION

•

When removing the upper hinge, be sure to

support the door as it will fall forwards. It is

recommended that two or more people carry out

the door removal and refitting.

4

Lift the upper hinge fixed between the

appliance and the appliance door and then

remove it.

Upper hinge

Door

5

Remove the freezer and fridge compartment

door by lifting it upward. At this time, the door

should be lifted enough for the steel pipe to be

completely pulled out.

Refitting the Door

Mount the doors in the reverse sequence of their

removal once the appliance has been passed

through all access doors.
