CUSTOMER SERVICE AND SPARE PARTS

If the appliance is not functioning properly, check
that:

•

the plug is firmly in the wall socket and the mains
power switch is on;

•

there is an electricity supply (find out by plugging
in another appliance);

•

If there are water drops on the bottom of the
cabinet, check that the defrost water drain
opening is not obstructed (see “Defrosting”
section).

•

If your appliance is still not working properly after
making the above checks, contact the nearest
service centre.

To obtain fast service, it is essential that when you
apply for it you specify the model and serial number
of your appliance which can be found on the
guarantee certificate or on the rating plate located
inside the appliance, on the bottom left-hand side.

To carry out complete defrosting of the freezer

compartment

proceed as follows:

1. Press button ON/OFF (I) ;
2. leave the door open, insert the plastic scraper in

the appropriate seating at the bottom centre,
placing a basin underneath to collect the defrost
water;

3. when defrosting is completed, dry the interior

thoroughly and refit the plug; keep the scraper for
future use;

4. Press button ON/OFF (I). After letting the

appliance run for at least half an hour, replace
the previously removed food into the
compartment.

Important:

Never use sharp metal tools to scrape off frost
from the evaporator as you could damage it.

Do not use a maechanical device or any artificial
means to speed up the thawing process other
than those recommended by the manufacturer.

D068

A temperature rise of the frozen food packs,
during defrosting, may shorten their safe storage
life.

TECHNICAL INFORMATION

205

70

0,805

294

13

24

Fridge Net Capacity lt.

Energy Consumption  kWh/24h

Energy Consumption kWh/annuo

Freezing Capacity  kg/24h

Rising Time

Freezer Net Capacity lt.

The Technical info are on the rating plate situated on the left inside the appliance.

17

CONTENTS

Warnings

 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Use  -

Cleaning the interior - Appliance/Freezer Control Panel  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Use -

Operation - Freezing fresh food

-

Storage of frozen food - Thawing -Ice-cube production -   . . . . . . . . . .

Cold Accumulators  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Use -

Fridge Control Panel- Operation  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Use  -

Movable shelves - Positioning the door shelves - Fresh food refrigeration  . . . . . . . . . . . . . . . . . . . . . . .21

Hints -

Hints for refrigeration - Hints for freezing - Hints for storage of frozen food  . . . . . . . . . . . . . . . . . . . . .22

Maintenance -

Periods of no operation - Periodic cleaning - Interior light - Defrosting  . . . . . . . . . . . . . . . . .23

Customer service and spare parts - Technical information

 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Installation -

Location  - Electrical connection  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Installation -

Dimensions of housing  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

•

Do not place carbonated or fizzy drinks in the
freezer as it creates pressure on the container,
which may cause it to explode, resulting in
damage to the appliance. Do not use a
mechanical device or any artificial means to
speed up the thawing process other than those
recommended by the manufacturer. Never use
metal objects for cleaning your appliance as it
may get damaged.

Installation

•  During normal operation, the condenser and

compressor at the back of the appliance heat up
considerably. For safety reasons, minimum
ventilation must be as shown in the instructions.

Attention: keep ventilation openings clear of
obstruction.

•  Care must be taken to ensure that the appliance

does not stand on the electrical supply cable.

Important:

if the supply cord is damaged, it must

be replaced by a special cord or assembly availa-
ble from the manufacturer or its service agent.

•  If the appliance is transported horizontally, it is

possible that the oil contained in the compressor
flows in the refrigerant circuit. It is advisable to
wait at least two hours before connecting the
appliance to allow the oil to flow back in the
compressor.

•  There are working parts in this product which

heat up. Always ensure that there is adequate
ventilation as a failure to do this will result in
component failure and possible food loss. See
installation instructions.

•  Parts which heat up should not be exposed.

Wherever possible the back of the product should
be against a wall.

Environment Protection

This appliance does not contain gasses which
could damage the ozone layer, in either its
refrigerant circuit or insulation materials. The
appliance shall not be discarded together with
the urban refuse and rubbish. Avoid damaging
the cooling unit, especially at the rear near the
heat exchanger. Information on your local
disposal sites may be obtained from municipal
authorities. The materials used on this appliance
marked by the symbol

are recyclable.

Disposal of old Appliances

The symbol

on the product or on its packaging

indicates that this product may not be treated as
household waste. Instead it shall be handed over to
the applicable collection point for the recycling of
electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent
potential negative consequences for the
environment and human health, which could
otherwise be caused by inappropriate waste
handling of this product. For more detailed
information about recycling of this product, please
contact your local city office, your household waste
disposal service or the shop where you purchased
the product.
