EN

Before reading on please unfold the pages
at the back with the illustrations.
This manual of operating instructions
applies to various models.
Some of the illustrated details may deviate
from those present in your model.

General View

Fig

a

1 Ventilation grid compartment
2 Control panel
3 Bearing trays
4 Rear wall of the refrigerator

compartment refrigerating unit)

5 Defrosting-water conductor
6 Defrosting wateroutlet
7 Glass plate
8 Vegetable baskets
9 Butter and cheese storage
10 Egg rack
11 Door shelf12 Bottle shelf
13 Bottle holder
14 Frozen food bins
15 Freezer calendar
16 Interior light
17 Defrosting drain
18 Ventilator

A Refrigerator compartment
B Freezer compartment

Control panel

Figure

s

21 Main switch
22 Super-freezer switch.
23 Temperature selector

Where to set-up

Set-up appliance in a dry, well ventilated
room. Do not expose appliance to direct
sunlight or place near a source of heat such
as: cooker, radiator etc. If placement of the
appliance near a source of heat can not be
avoided, use an adequate insulation plate or
observe the following safety distances
between appliance and source of heat:

3 cm distance from cooker
30 cm distance to oil or gasboiler.

If the appliance is placed next to another
refrigerator or freezer, keep a side clearance
of 2 cm between them to prevent
condensation.

Setting-up and changing the

door hinging side

See enclosed manual for installation and
modifications.

Electrical Connection

Connect appliance to a 220-240 V/50 Hz
supply only. Protect with a 13 ampere fuse.
The connection must be made via a
properly installed socket with a non-fused
earthing.

Ventilation

The air heated at the back of the appliance
must be able to escape unhindered.
Otherwise, the refrigerating machine must
work harder and use-up more electricity.
Consequently, the ventilation inlet grill must
never be covered.

Getting to know the

appliance

Setting-up the Appliance

15
