Oursson EG2010S/RD - Инструкция по эксплуатации - Страница 4

6

7

•

Whip the body of the device with a damp soft cloth.

•

Never immerse the device in water due to the

danger of electric shock.

•

After cleaning, thoroughly dry all the parts of the device.

•

Store the product with the lid closed.

ELEMENTS OF DESIGN,

 Рiс. B

Heating element

Removable heating plates

Operation indication

Heating indication

Сontrol Panel

Grease/oil drain groove

Handle

Buttons for fixating heating plates

Lid closing height adjuster

180° lid opener fixator

Removable grease tray

ORDER OF OPERATION

1.  Plug in the device. Make sure that the grease tray is

installed and the lid is closed.

2.  Turn the ON/OFF switch into the   , position, the

power indicator will light up  .

3.  Set the required temperature with the help of heating

regulator, according to cooking recommendations

(see table below). When the device reaches the set
temperature, the indicator lights up  , grill is ready to

use.

4.  Open the grill by pulling up the handle. If necessary,

grease the heating plates with a small amount of oil

or other grease. The use of oil/grease is optional,

as heating plates are made of non-stick coating

elements. Place the prepared ingredients on the

heating plates, Pic.C-5. Lower the lid down until it

locks. The cooking process will begin.

NOTE:

•

If necessary, adjust the closing height of the lid

using the knob

9

.

•

If an increase in cooking area is required, press

the lid opener fixator

10

 and spread the grill 180°.

It is recommended to perform this operation

before plugging the device to the electrical

network.

You can check the readiness of the dish at any

time by lifting the lid. Be careful not to get hot

steam or grease spray on your skin.

•

During cooking, the heat indicator   may fade.

This indicates the maintenance of the required

temperature.

5.  At the end of cooking, open the grill. Using special

kitchen utensils (plastic, silicone or wooden) take the

finished dish from the grill and put it on a plate. Turn

the temperature control to the

MIN

, position and the

ON/OFF switch into the   position,   indicator will

fade.

Before unplugging the device always set the

heating control to the

MIN

 position.

6.  Unplug the device.

2
3
4
5
6
7
8
9

10

11

UTILIZATION

Control panel, Рiс.  B-5

ON/OFF switch

Switch position:

- ON position, turn on the grill

- STOP position, turn off the grill

HEATING REGULATOR, temperature adjustment:

- MIN position, 0°C
- DEFROST position
- Recommended position for toasts and
sandwiches
- Maximum temperature recommended for cooking
meat.

PREPARATION FOR OPERATION,

 Pic. С

Before first use, wipe the body of the device with a soft,

dry cloth.

Press from the both sides the buttons for fixating

heating plates and remove the plates, Pic. C-1. Take out the

grease tray, Pic.C-2. Rinse the heating plates and grease

tray with

warm water

 and dishwashing liquid. Thoroughly

dry all parts. Set them back.

Before assembling or

disassembling the device, make sure that the device

is unplugged.

Turn on empty device for 15 minutes to

remove the odor of the new device. To do this, turn the knob
into the   , position, set max temperature by turning the
knob to   position. Air the room. Allow the device to cool.

MIN

Do not use sharp objects, as this may

damage the non-stick coating, Pic. А-2.

Ingredients

Type of Cooking

Cooking time

Vegetables, mushrooms

9-17 min.

•

Before cooking it is recommended to wash the ingredients, cut them and marinade if necessary.

•

The cooking time in the table is advisory in nature and may vary depending on the recipe and personal preferences.

•

When using the grill in the unfolded position of 180 °, the cooking time increases. Turn the ingredients periodically during

cooking.

Note:

Frozen food should be completely thawed before grilling, then wipe the heating plates dry.

COOKING RECOMMENDATIONS

Ingredients

Type of Cooking

Cooking time

Toasts, sandwiches

4-9 min.

Fish

4-12 min.

Sausages

5-10 min.

Meat

10-25 min.

Chicken

25-30 min.

Defrosting

PRODUCT SET

Electric Grill  .............................................................

1 ш т.

Instructions manual ..................................................

1 шт.

Guarantee sheet .......................................................

1 шт.

CLEANING AND  MAINTENANCE,

Pic. D

•

Make sure the temperature control is in the

MIN

position and the ON/OFF switch is in the    position.

Unplug the device.

Let the device cool.

•  Press from the both sides the buttons for fixating

heating plates and remove the plates, Pic. C-1. Take

out the grease tray, Pic.C-2. Rinse the heating plates

and grease tray with warm water and dishwashing

liquid. They can be washed in a dishwasher.

The

temperature in the dishwasher should not exceed

60°C.

Clean all the parts of the device immediately

after use
