3

2.  Close supervision is necessary when any appliances are used by or near children.

3.  To protect against electric shock, do not immerse cord, plug, or any parts of the oven in water or other liquid.

4.  Do not let cord hang over edge of table or counter, or touch hot surfaces.

5.  Do not operate appliances with damaged cord or plug or after the appliances malfunctions, or has been

damaged in any manner. Return appliances to the nearest Authorized Service Center for examination, repair, or

adjustment.

6.  The use of accessory attachments not recommended may cause hazard or injury.

7.  Do not place on or near a hot gas or electric burner, or in a heated oven or in a microwave oven.

8.  Unplug from outlet when not in use and before cleaning. Allow cooling before putting on or taking off parts, and

before cleaning.

9.  To disconnect, turn the control to OFF, then remove the plug, Always hold the plug, but never pull the cord.

10. Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.

11. Do not use outdoors.

12. Do not use appliance for other than intended use.

13. Do not put or store any flammable liquid, gas or other objects around the product.

14. The working voltage of the equipment should match that of the power supply.

15. There is an earth bolt at the back of the epuipment. Please connect the earth wire in compliance with the safety

regulations reliably with copper cable of no less than 2mm.

16. Before using user should check whether connection is firm and voltage is regular and earth connection is safe.

17. Do not store any flammable objects near the equipment. The environment Temperature lower than 45

℃

, the

humidity is under 85%.

18.The installation and maintenance of the equipment should be made by professional technicians.

Technical

inf ormation

Model

EG-01 EG-02  EG-03  WM1

Voltage

220~240V 220~240V  220~240V  220~240V

Frequency

50/60Hz 50/60Hz  50/60Hz 50/60Hz

Power

1,8KW 2,2KW  3,6KW  1KW

Controller number

1 1  2  1

Temperature range

50~300

℃

 50~300

℃

 50~300

℃

 50~300

℃

Dimension

290×395×210(mm) 410×370×220(mm)  570×395×210(mm) 440x260x260(mm)

Weight

14kg 15,5kg 28,5kg  6Kg

Operation

Instruction

1.Before using, check whether the power supply installation is regular to make sure the supplied voltage is

coordinated with the using one.

2.Put the plug in the socket and turn on the power.

3.Turn the temperature controller clockwise to the temperature needed. The yellow indicator is on that shows heating

wire begins to heat and the upper and lower griddle begins to raise temperature.

4.Temperature can be adjusted according to different food preferably within 180

℃～

250

℃

. About 8 minutes is

needed for the temperature to be raised to 250

℃

 from the power is on.

5.When the temperature reaches 250

℃

, lift the upper module plate to a suitable place by operation handle. Put

some edible vegetable oil on the lower module plate and constantly place the food on it. Close the plates and press

the handle lightly. Keep an eye on the food until it is suitably done.

6.When temperature reaches the setting degree, temperature controller can cut Off power supply automatically. At

the same time, yellow indicator is off and green indicator is on. It shows that electricity heating tube stops working

for next turn.

7.At the lower front of the lower module is the oil tray. Substantial vegetable oil and the animal oil from the meat grilled

flow to the oil tray from the lower module plate.
