To ensure you have a secure connection between
the lawnmower and the extension cable we strongly
recommend you use the following method of
attaching the cable:
1.  Plug the short connection lead into the socket of

the extension cable.

(M1)

.

2.  Form a loop in the end of the extension cable

near to the socket and secure this in the strain
relief feature at the top of the switchbox.

(M2)

This will cause the socket to hang in a
downward direction.

(M3)

ENGLISH - 2

Safety

2. Avoid operating your product in wet grass,

where feasible.

3. Take care in wet grass, you may lose your

footing.

4. On slopes, be extra careful of your footing

and wear non-slip footwear.

5. Operate your product across the face of

slopes, never up and down.

6. Exercise extreme caution when changing

direction on slopes. Walk never run.

7. Using on banks and slopes can be

dangerous.  Do not mow on

banks

or

 steep

slopes.

8. Do not walk backwards when operating, you

could trip.

9. Never cut grass by pulling the product

towards you.

10.Switch off before pushing the product over

surfaces other than grass.

11. Never operate the product with damaged

guards or without guards in place.

12.Keep hands and feet away from the cutting

means at all times and especially when
switching on the motor.

13.Do not tilt product when the motor is running,

except when starting and stopping.  In this
case, do not  tilt more than absolutely
necessary and lift only the part which is away
from the operator.  Always ensure that both
hands are in the operating position before

returning the appliance to the ground.

14.Do not put hands near the grass discharge

chute.

15.Never pick up or carry a product when it is

operating or still connected to the mains
supply.

16.Remove the plug from the mains :
-

before leaving the product unattended for any
period;

-

before clearing a blockage;

-

before checking, cleaning or working on the
appliance;

-

if you hit an object.  Do not use your product
until you are sure that the entire product is in
a safe operating condition.;

-

if the product starts to vibrate abnormally.
Check immediately.  Excessive vibration can
cause injury.

Maintenance and storage

1. Keep all nuts, bolts and screws tight to be

sure the product is in safe working condition.

2. Check the grassbox frequently for wear or

deterioration.

3. Replace worn or damaged parts for safety.
4. Only use the replacement blade and blade

bolt specified for this product.

5. Be careful during adjustment of the product to

prevent entrapment of the fingers between
moving blades and fixed parts of the
machine.

Safety Cut-Out

The Motor is protected by a Safety Cut-Out which
is activated when the blade becomes jammed or if
the motor is overloaded.  When this occurs, stop
and remove the plug from the power supply.  The

Safety Cut-Out will only reset when the start/stop
lever is released.  Clear any obstruction and wait
for a few minutes for the Safety Cut-Out to reset
before continuing to use the mower.

Removing and Fitting the Blade

Switch off, wait until the blade has stopped
rotating and disconnect from the mains
electricity supply BEFORE attempting to
remove or refit the blade.
Always handle the blade with care - sharp
edges could cause injury.  USE GLOVES.
Removing the Blade
R1 - blade bolt    R2 - washer         R3 - blade

1. To remove the blade bolt, hold the blade firmly

with a gloved hand and with a spanner, loosen
the blade bolt by turning it anti-clockwise

(R)

.

2. Remove the blade bolt, washer and blade.

(R)

3. Inspect for damage and clean as necessary.
4. In the event of a blade becoming difficult to

remove, insert a screwdriver

(S1)

into the hole

(S2)

to lock the drive, then use a spanner to

loosen the blade bolt by turning the spanner anti-
clockwise.  Ensure the screwdriver is removed
before atempting to turn on the machine.

Renew your metal blade after 50 hours mowing
or 2 years whichever is the sooner - regardless
of condition. If the blade is cracked or
damaged replace it with a new one.
Fitting the Blade

1. Fit the blade to the shaft with the sharp edges

of the blade pointing away from the shaft.

2. Re-assemble blade bolt through the washer

and the blade.

3. Hold the blade firmly with a gloved hand and

tighten the blade bolt firmly with a spanner .
Do not over tighten.
