21

STANDARDS OF USE

NOTE – The machine can be supplied with some of the
components already fitted.

Attach the stone-guard by inserting the pin (1) and

the spring (2) as shown.  First, insert the pin into the right-
hand housing (4).  Next fit the eyelet end (3) of the spring
into the central slot, and lastly insert the other end of the
pin in place (5).

Insert the lower right part (1) and lower left part (2) of

the handle into the respective holes and lock into position
with the screws (3) supplied.
Attach the upper part of the handle (4) to the lower parts
using the knobs (5) and the nuts and bolts supplied as
shown. Attach the cable clamp (6) to the position shown
and then attach the cable (7). The correct position of the
electric cable hook (8) is as shown.

Assemble the two parts (1) and (2), making sure that

the hooks are fully clicked into position.

To attach the wheels, follow the steps shown. Attach

the wheels selecting one of the holes for the preferred cut-
ting heights, fully tightening the pin (1) using the wrench (2)
provided.

The engine is controlled by a dual action switch to

prevent starting it accidentally. To start, press the button (2)
and pull the lever (1). The engine automatically stops when
the lever (1) is released.

The cutting height is adjusted by attaching the

wheels to the required hole, fully tightening the pin (1) using
the wrench (2) provided. All the wheels must be at the same
height.
MAKE THIS ADJUSTMENT ONLY WHEN THE BLADE IS
STOPPED.

Lift the stone-guard and attach the grass-catcher

(1) correctly as shown in the drawing.

Connect the extension cable correctly as indicated.

Start the engine by pressing the safety push-button (2) and
pulling the switchgear lever (1).

3.2

3.1

3. GRASS CUTTING

2.2

2.1

2. DESCRIPTION OF CONTROLS

1.4

1.3

1.2

1.1

1. FINISH ASSEMBLY

GB

While cutting, ensure that the electric cable is

always behind you and on the area of grass already cut.
The lawn will look better if it is always cut to the same
height and in alternate directions.

When you have finishing mowing, release the lever

(1). FIRST disconnect the cable extension from the supply
socket (2) and THEN from the side of the lawnmower’s
switchgear (3).
WAIT FOR THE BLADE TO STOP before carrying out any
type of work on the machine.

IMPORTANT – Regular, careful maintenance is essen-
tial for keeping the safety level and original perform-
ance of the machine unchanged in time.
Store the lawnmower in a dry place.

1) Wear strong working gloves during any cleaning, main-

tenance or adjustment operation on the machine.

2) Remove the grass debris after each cut and mud accu-

mulated inside the chassis to avoid their drying and thus
making the next start-up difficult.

3) Always ensure that ventilation openings are kept clear of

debris.

All operations on the blade should be carried out at

a specialized centre.

Note for specialized centres:

Reassemble the blade (2) as

shown in the drawing and tighten the central screw (1)
using a torque wrench set to 16-20 Nm.

Do not use forced water and avoid wetting the

motor or the electrical components.
Do not use harsh products for cleaning the chassis.

Should you have any doubts or problems, do not hesitate
to contact your nearest Service Centre or your Dealer.

4.2

4.1

4. ROUTINE MAINTENANCE

3.4

3.3
