Where to Use Your GARDENA PowerMax 36 E/42 E Mower

The GARDENA mower is designed for cutting lawns
in and around the garden.
Do not use the mower on a slope steeper than 20°
maximum.

To prevent injury, the mower must not be used for
trimming bushes, hedges, shrubs, for cutting and
pruning of climbers or grass on roofs or in balcony
boxes.  In addition, the mower must not be used for
chopping up branches, twigs or for levelling
irregularities in the soil.

1. Pull the lower handle bolt until it locks into position

as illustrated in

fig B1

.

2. Place the Spring over the Bolt

(B2)

3. Insert the Pivot Block on to the Bolt

(B3)

Repeat for the other side.

4. Insert the Barrel Nut into the Cam Lock as illustrated

in

fig C1.

5. Ensuring the Lower Handle is in the correct position

(C2)

,

insert the Lower Handle

(D1)

on to the Bolt

(D2)

until it is

firmly fitted into the Pivot Block

(D3)

.

6. Place the Washer

(D4)

and Cam Lock

(D5)

on to the Bolt

(D2)

and turn the Cam Lock 3 times clockwise, as

illustrated in

fig E1

.

7. Ensuring the raised markings on the Cam Lock and

the deck are aligned

(E2)

, fold down the Cam Lock

towards the Handle as illustrated in

fig E3

, and

continue to turn clockwise

(E4)

until tightened.

8. The Cam Lock can be unlocked and locked as

illustrated in

fig E5

.

Repeat for the other side.

9. Insert the two Lower handle plugs into the top of

each of the Lower handles

(E6)

.

Grassbox Assembly

Grassbox Handle Assembly

1. Locate the grassbox handle into the slots in the grassbox

upper and push until it clicks into position.

(

G1)

2. Looking at the underside of the lid

(G2)

, ensure the

clips of the grassbox handle are securely located.

Grassbox Assembly

1. Locate the the grassbox halves together by aligning

the clips   Ensure all clips are correctly located before
clicking into position.

(H1)

2. Locate the grassbox lid onto the assemble grassbox by

aligning the clips.  Ensure all clips are correctly located
before clicking into position

H2)

Fitting Fully Assembled Grassbox to Lawnmower.

1. Lift safety flap

(J1)

2. Make sure the discharge chute is clean and free

from debris

(J2)

3. Locate fully assembled grassbox onto 2 location

points

(J3)

at the rear of the deck as illustrated in

pic. K

4. Locate safety flap onto the top of the grassbox.

Ensure the grassbox is securely located.

• IMPORTANT !   AFTER FITTING ENSURE NO GAP

REMAINS BETWEEN THE SAFETY FLAP AND
THE GRASSBOX.

•

Removal is the reverse procedure.

•

For larger areas of grass where grass collection is not
required you can use your lawnmower without the
grassbox.  Ensure the Safety Flap is fully closed.  The
design of the safety flap permits the cut grass to be
discharged downward behind the machine.

Cutting Height Adjustment

•

Height of cut is adjusted by raising or lowering the
wheels using the height adjustment lever

(L1)

•

There are five heights of cut on this product (20 - 60
mm).

• NOTE

A medium height of cut is recommended for most
lawns.  The quality of your lawn will suffer and
collection will be poor if you cut too low.

Starting and Stopping

To Start your Lawnmower

1. Attach the extension cable to the back of the switchbox.

(M1)

2. Form a loop in the cable and push the loop through

the slot.

(M2)

3. To secure, position the loop over the hook and pull

the cable back through the slot

(M3)

.

4. Connect the plug to the mains and switch on.

The switchbox is provided with a lock-off button
(M4) to prevent accidental starting.

6. Press and hold the lock-off button

(M4)

on the

switchbox, then squeeze one of the Start/Stop levers
towards the upper handle

(M5)

.

7. Continue to squeeze the start/stop lever towards the

upper handle and release the lock-off button

(M6)

.

• NOTE - There are two start/stop levers fitted. Either

one can be used for starting the lawnmower.

• IMPORTANT - Do not use the start/stop levers

intermittently

To Stop your Lawnmower

1. Release the pressure on the Start/Stop lever.

IMPORTANT INFORMATION

When received from the Manufacturer, the wheels are in a raised position.  Do not switch
on the product before removing from the raised position into position 5. (See fig A)

Assembly of Lower Handles to Lawnmower

Assembly of Upper Handles to Lower Handles

1. Insert the Barrel Nut into the Cam Lock as illustrated

in

fig F1.

2. Attach the Upper Handle to the Lower Handle with

the Round Headed Bolt, Washer and Cam Lock as
illustrated in

fig F2

3. Turn the Cam Lock 3 times clockwise, as illustrated

in

fig F3

.

4. Fold down the Cam Lock towards the Handle as

illustrated in

fig F4

, and continue to turn clockwise

(F5)

until tightened.

5. The Cam Lock can be unlocked and locked as

illustrated in

fig F6

.

Repeat for the other side.

ENGLISH - 2
