16

 | English

F 016 L70 847 | (17.8.12)

Bosch Power Tools

Press the button  to actuate the charge-control indicator . Af-

ter approx. 5 seconds, the charge-control indicator goes out

automatically.
The charge condition can also be checked when the battery is

removed.

When no LED lights up after actuating the button  , the battery

is defective and must be replaced.
For safety reasons, the charge condition of the battery can

only be checked when the garden product is at a standstill.
During the charging procedure, the three green LEDs light up

one after the other and briefly go out. The battery is fully

charged when the three green LEDs light up continuously. The

three LEDs go out again approx. 5 minutes after the battery

has been fully charged.

Temperature Control Indicator

The red LED  signals that the battery or the electronics of the

garden product (with battery inserted) are not within the op-

timum temperature range. When this occurs the garden prod-

uct will not operate or not at full capacity.

Temperature Control of the Battery

The red LED  flashes when pushing button  or pressing the

On/Off switch  (when the battery is inserted): The battery is

not wihin the temperature range for operation of  – 10 ° C to

+ 60 ° C.
The battery switches off at a temperature above 70 ° C until

the optimum temperature range is reached again.

Temperature Control of the Garden Product

Electronics

The red LED  lights up

continuously

 when pressing the On/Off

switch : The temperature of the garden product electronics is

below 5 ° C or above 75 ° C.
At a temperature above 90 ° C, the electronics of the garden

product switch off until the temperature is within the allowa-

ble temperature range again.

Area of Cut (Battery Duration)

The area of cut (battery duration) depends on lawn condi-

tions, grass density, mositure content, grass length and

height of cut.
Switching the machine on and off frequently during cutting

will also reduce the area of cut (battery duration).
To improve the area of cut (battery duration) it is recommend-

ed to cut more frequently, raise the cutting height and walk at

a normal pace.
The example below shows impact of conditions against run

time, for one battery.

To increase the run time an additional battery or higher capac-

ity battery (Ah) can be purchased from an authorised custom-

er service agent for Bosch garden products.

Troubleshooting

LED Indicators

Battery Capacity

Continuous lighting of 3 green LEDs

≥

2/3

Continuous lighting of 2 green LEDs

≥

1/3

Continuous lighting of 1 green LED

≤

1/3

Flashing of 1 green LED

Reserve

Cutting Conditions

Very light, dry grass

Light, dry grass

Area of cut (Rotak 32 LI)

up to 150 m

2

up to 100 m

2

Area of cut (Rotak 32 LI High Power)

up to 300 m

2

up to 150 m

2

6cm
4cm

8cm

4cm

STOP

Problem

Possible Cause

Corrective Action

Tool fails to operate

Possible clogging

Remove the isolator key:

Check underneath the garden product and clear

out as necessary (always wear gardening gloves)

Battery not fully charged

Battery Charging

Battery not inserted (properly)

Inserting the battery

Grass too long

Increase height of cut and tilt garden product to re-

duce starting load

Motor protector has activated

Allow motor to cool and increase height of cut

Battery too hot/cold

Allow to cool/warm

Isolator key not inserted correctly/fully

Fit correctly

There is a short delay in the motor starting after

engaging the On/Off switch

Hold On/Off switch for 1 – 3 s to start motor
