Startup

474833_a

17

DANGER!

The  travel  drive  is  not  allowed  to

start  moving  until  the  lever  has  moved

through half of its travel, adjust the Bow-

den cables if necessary – (see: Adjusting

Bowden cables).

Version with forward and reverse gears

(12)

Clutch lever

(12-1)

 = travel drive forwards

Clutch lever

(12-2)

 = travel drive backwards

WARNING!
Do  not  pull  both  clutch  levers  at  the

same time!

Travel drive forwards

or

Travel drive backwards
Not both

Switching off travel drive

(12)

Release clutch lever

(12-1)

 or

(12-2)

.

Switching off scythe attachment

(11)

Release clutch lever

(11-2)

.

Switching off engine

(13)

Move throttle lever to the << STOP >> position.

SCYTHE ATTACHMENT

Clean the scythe attachment after each use, es-

pecially  the  guidance  and  sliding  surfaces.  Re-

move the mowing blade to do this.
Then oil all moving parts.

Only use biodegradable lubricants!
Removing mowing blade on the scythe at-

tachment
Standard scythe attachment

(14, 15)

1. Unscrew screws

(14-1)

.

2. Remove part

(14-2)

 forwards.

3. Note  the  installation  direction  when  reinstal-

ling the part – projection in travel direction!

4. Loosen guides for mowing blade

(15)

.

5. Unscrew hex nuts and unscrew threaded pins

a little.

6. Pull out mowing blade to the side..
Re-install in the reverse sequence.

Setting the cutting play

(15)

1. Screw in the threaded pins by hand until you

can feel resistance – then continue ½ a turn

further.

2. Secure the threaded pins with a locknut.
3. It  must  still  be  possible  to  move  the  mowing

blade  freely  by  hand  after  the  setting  proce-

dure.

4. Make  a  trial  cut  –  screw  the  threaded  pins

slightly further in if the cutting performance is

insufficient.

ESM scythe attachment

(14)

1. Unscrew screws

(14-1)

.

2. Remove part

(14-2)

 forwards.

3. Note  the  installation  direction  when  reinstal-

ling the part 2 – projection in travel direction!

For further information about removal of the mo-

wing blade as well as maintenance of the scythe

attachment,  see  the  accompanying  document:

ESM scythe attachment Universal SC

ADVICE

3 grease nipples

(16-1, 17)

Grease  driver

(16)

  and  drive  for  scy-

the  attachment

(17)

  every  8  working

hours with commercially available multi-

purpose grease.

Regrinding and renewing blades

Regrind blunt blades using a suitable whetstone,

maintaining the cutting angle (approx. 35 – 40°) –

remove the mowing blade to do this.
Renew worn or damaged blades – customer ser-

vice workshop.

Have a professional check:

after bumping against an obstacle
if the engine stops suddenly
if the cutter bar is bent
if the gears are damaged
if the belt is damaged.

TRAVEL TRANSMISSION

(18)

Regularly check the oil level in the transmission
1. Position the machine horizontally.
2. Unscrew and remove the oil filler cap.
3. Oil  level:  Up  to  the  bottom  edge  of  the  fill

opening. Top up gear oil if necessary.

Oil grade

Gear oil SAE 80

Oil fill volume for machines with
Forwards gear only

approx. 0.25 l
